Hyundai Electronics H-AP3-09H-UI004 - Инструкция по эксплуатации - Страница 9

9.

Electric air conditioner
portable type

EN

NOTE:

The unit can evaporate condensed water and automatically drain it

through the hose.

1. When the unit is in cooling mode, it is not necessary to install the

condensate drainage pipe since condensate evaporates automatically.

Make sure that when the unit is operating, the rubber plug of the

drainage hose is securely fixed.

2. In heating mode, remove the rubber plug of the drainage hose,

install the respective drainage hose to improve heating efficiency.

3. In dehumidification mode, remove the rubber plug of the drainage

hose, install the respective drainage hose.

Disconnect the air outlet hose, connect the drainage hose to the

drainage hole and drain water from the unit to ensure maximum

dehumidification efficiency.

“E4” signal is shown on the LED display at the maximum water level.

To resume the operation, remove the rubber plug of the drainage

hose to drain water at first. After water is drained, turn the unit on,

the unit will resume operation.

6. MAINTENANCE

1.

When cleaning the air conditioner, do not use gasoline, solvents and other chemically active

substances.

2.  To avoid electric shock and damage to electrical components, do not pour water on the air

conditioner from a tap or a hose.

3.

Do not use the air conditioner if the power cord is damaged. On the subject of replacing a

damaged power cord, contact an authorized service center.

Air filter

Air filter clogging with dust particles impairs the air conditioner operation efficiency, therefore

clean the filter no less than once in two weeks.

Filter removal/installation

Remove the air filter in the direction, indicated by the arrow. Slightly push it and then take it out

from the device for cleaning. (See Fig. 7).

IMPORTANT!

Disconnect the unit from the mains prior to cleaning.
