Function buttons

1

2

 Each time the button is pressed, the operation

 mode is selected in a sequence of  following:

3

MODE  Button

4

5

ON/OFF Button

Operation starts when this button is pressed

and stops when this button is pressed again.

AUTO

COOL

DRY

HEAT

FAN

SHORTCUT Button

 TIMER ON Button

 TIMER OFF Button

Used to restore the current settings or resume previous settings.

On the first time connecting to the power, if push the SHORTCUT button, the unit

O

will operate on AUTO mode, 26 C, and fan speed is Auto.

Push this button when remote controller is on, the system will automatically revert

back to the previous settings including operating mode, setting temperature, fan

speed level and sleep feature(if activated). And transmit the signals to the unit.

If pushing more than 2 seconds, the system will automatically restore the current

operation settings including operating mode, setting temperature, fan speed level

and sleep feature(if activated ).

8

6

7

     SWING Button

     DIRECT Button

Used to change the louver movement and set the desired up/down air flow direction.

O

The louver changes 6  in angle for each press.

NOTE: On some models operate swing feature instead of this feature.

SELF CLEAN  Button

UP Button(           )

o

Push this button to decrease the indoor temperature setting in 1 C increments

o

to 17 C.

DOWN Button(            )

9

11

13

12

14

15

10

Used to select the fan speed in four steps:

    AUTO     LOW     MED     HIGH

FAN Button

Press this button to initiate the auto-on time sequence. Each press will increase

the auto-timed setting in 30 minutes increments. When the setting time displays

10.0, each press will increase the auto-timed setting 60 minutes increments.

To cancel the auto-timed program, simply adjust the auto-on time to 0.0.

Press this button to initiate the auto-off time sequence. Each press will increase

the auto-timed setting in 30 minutes increments. When the setting time displays

10.0, each press will increase the auto-timed setting 60 minutes increments.

To cancel the auto-timed program, simply adjust the auto-off time to 0.0

1

2

4
5

3

9

10

8

6

7

11

12

13

14
15

ON/OFF

MODE

FAN

TEMP

SHORT

   CUT

TIMER ON

TIMER OFF

SLEEP  FRESH

SWING  DIRECT

LED  FOLLOW ME

TURBO SELF CLEAN

Active/Disable Self Clean function

SLEEP Button

FRESH Button

NOTE:

While the unit is running under SLEEP

mode, it would be cancelled if MODE, FAN

SPEED or ON/OFF button is pressed.

Active/Disable sleep function. It can maintain

the most comfortable temperature and save

energy. This function is available on COOL,

HEAT or AUTO mode only .

Active/Disable

When the

FRESH function is initiated, the Ionizer/Plasma

Dust Collector(depending on models) is

energized and will help to remove pollen and

impurities from the air.

FRESH function.

TURBO Button

Active/Disable Turbo function. Turbo function

enables the unit to reach the preset temperature

at cooling or heating operation in the shortest

time(if the indoor unit does not support this

function, there is no corresponding operation

happened when pressing this button.)

LED Button

Disable/Active indoor screen Display. When

pushing the button, the indoor screen display

is cleared, press it again to light the display.

o

Push this button to increase the indoor temperature setting in 1 C increments

o

to 30 C.

FOLLOW ME Button:

  Push this button to initiate the Follow Me feature, the

remote display is actual temperature at its location. The remote control will send

this signal to the air conditioner every 3 minutes interval until press the Follow Me

button again. The air conditioner will cancel the Follow Me feature automatically

if it does not  receive the signal during any 7 minutes interval.

Used to stop or start horizontal louver auto swing feature.

NOTE; On some models used to stop or start vertical louver auto swing featrue.

For the detail, see   sleep operation   in

  USER S MANUAL.

,

, ,

, ,

,,

,,

NOTE

：

Please do not select HEAT mode if

the machine you purchased is cooling only

type. Heat mode is not supported by the

cooling only appliance.
