Use the remote controller within a distance of 8

meters from the appliance, pointing it towards the

receiver. Reception is confirmed by a beep.

Location of  the remote controller.

8m

CAUTIONS

The air conditioner will not operate if curtains, doors or other materials

block the signals from the remote controller to the indoor unit.

Prevent any liquid from falling into the remote controller. Do not expose

the remote controller to direct sunlight or heat.

If the infrared signal receiver on the indoor unit is exposed to direct

sunlight, the air conditioner may not function properly. Use curtains to

prevent the sunlight from falling on the receiver.

If other electrical appliances react to the remote controller, either move

these appliances or consult your local dealer.

Replace the batteries when there is no answering beep from the indoor

unit or if the transmission indicator light fails to light.

The remote controller is powered by two dry batteries(R03/LR03X2) housed in the

rear part and protected by a cover.

(1) Remove the cover by pressing and sliding off.

(2) Remove the old batteries and insert the new batteries, placing the(+) and (-)

      ends correctly.

(3) Reattach the cover by sliding it back into position.

NOTE:

When the batteries are removed, the remote controller erases all progra-

mming.  After inserting new batteries, the remote controller must be reprogrammed.

Replacing batteries

Handling the remote controller

2

CAUTIONS

Do not mix old and new batteries or batteries of different types.

Do not leave the batteries in the remote controller if they are not

going to be used for 2 or 3 months.

Do not dispose batteries as unsorted municipal waste. Collection of such

waste separately for special treatment is necessary.
