Overview of the Components

1  Permanent filter

2  Water tank

3  Water outlet

4  MAX Mark for 1 cup (120 ml)

5  Water tank lid

6  MAX Mark for 2 cups (240 ml)

7  Filter holder

8  Power cord with plug

9

I/O

– On/Off switch with integrated power indicator lamp

10  Cup shelf (removable)

11  Cup

Initial Operation of the Device

1.  Remove all packaging and transportation safety devices

from the device that may be present.

2.  Rub all of the parts with a damp cloth. This will remove any

dust that may have accumulated during transport.

3.  Reinsert all of the parts in the reverse order.

4.  Rinse the permanent filter and the cups clean in a bowl of

water.

NOTE:

Before making coffee for the first time, allow water to pass

through the device two to three times in order to clean it.

Electrical Connection

NOTE:

Please ensure that the device is switched off. The switch

must be on “

O

”.

Insert the mains plug into a properly installed socket with earth-

ing contact. For information please see the type plate on the

device.

Operation

NOTE:

•  You can brew 1 cup or 2 cups of coffee.

•  If brewing 2 cups, we recommend that you brew them at

the same time and not consecutively, since otherwise the

coffee in the first cup is stronger than that in the second

cup.

1.  Fold open the water tank lid.

2.  Fill the water tank with cold water.

CAUTION:

Do not overfill the tank! Do not fill above the marks for the

maximum quantity of water.

3.  Push the water outlet to the side so that you can take out

the filter. Then pull the permanent filter out. For one cup, fill

to a maximum of 6 g / for 2 cups a max. 12 g coffee powder

in the permanent filter. If more coffee powder is used, there

is risk of overflowing. Reinsert the permanent filter. Push

the spout back over the filter.

4.  Place the cup(s) on the cup shelf and close the water

tank lid. If you only brew 1 cup, make sure that they are

positioned precisely under the brew head.

5.  Position the switch in position “

I

”. The brewing is started.

You can remove the cup(s) after the brew process.

NOTE:

•  The power indicator lamp lights up.

•  The brewing process lasts approximately 3 minutes.

6.  Turn the device off. The control lamp goes out.

WARNING:

If you would like to make another cup of coffee immedi-

ately, switch the device off. Allow it to cool down with the

water tank open in order to prevent hot water splashing

out when the machine is refilled.

Descaling

It is necessary to descale the coffee machine if the preparation

time becomes considerably longer.
•  Only a commercially available decalcifier on a citric acid

base should be used for descaling.

•  Please use the quantities stated on the pack or instruction

leaflet. Keep to the maximum water quantity for 2 cups!

•  Place the cups or another suitable vessel (for around

250 ml) onto the cup shelf.

WARNING:

•  Afterwards you should boil fresh water in the pot three or

four times in order to rinse out residues of the descaling

agent.

•  Do not use any coffee powder!

•  Do

not

 use this water for consumption.

Cleaning

WARNING:

•  Before cleaning, always remove the mains plug and wait

until the device has cooled down.

•  Do not immerse the device in water. Otherwise this might

result in an electric shock or fire.
