5

en

1

Mains switch

J

2

Control panel (see next page)

3

Display

4

Drinks outlet (coffee, milk, hot water),

height-adjustable

a)

Cover

b)

Milk system /coffee outlet (two-part)

c)

Milk tube

d)

Suction pipe

5

Removable water tank

6

Lid for water tank

7

Storage compartment for measuring

spoon

8

Measuring spoon

(insertion aid for water filter)

9

Bean container

10

Aroma cover

11

Dial selector for grinding level

12

Drawer

(for ground coffee/cleaning tablet)

13

Door to brewing unit

14

Brewing unit

a)

Locking mechanism

b)

Cover

15

Eject lever

16

Storage compartment

for quick reference guide

17

Drip tray

a)

Drip tray panel

b)

Drip plate

c)

Coffee grounds container

d)

Floater *

18

Compartment for power cord

19

Rating plate (E number, FD)

* These user instructions describe a number

of appliance versions� Items marked * are

not present in all models�

Overview

(Figures

 B, C, D, E, F

 and

 G

 on the fold-out

pages)

Included in delivery

(Figure

 A

 on the fold-out pages)

a

Fully automatic coffee machine

b

User Manual

c

Quick reference guide

d

Milk tube and suction pipe

e

Water hardness testing strip

f

Measuring spoon
