IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

- 3 -

General

Unpack the appliance carefully and retain the packaging for

possible future use, in the event of moving or returning the fire to

your supplier.
Before connecting the appliance check that the supply voltage is

the same as that stated on the appliance.
Please note: Used in an environment where background noise is

very low, it may be possible to hear a sound which is related to the

operation of the flame effect. This is normal and should not be a

cause for concern.

Electrical connection

WARNING - THIS APPLIANCE MUST BE EARTHED
This appliance must be used on an AC ~ supply only and the

voltage marked on the appliance must correspond to the supply

voltage.
Before switching on, please read the safety warnings and operating

instructions.

Transportation fixings

- see

Fig. 8

The transport bracket must be removed from the fire prior to

installation, remove the 2 screws and the bracket.
Warning: This bracket must be removed before installation; failure

to do this will result in having to uninstall the product in order to

replace a defective bulb.

Installation

 - see

Fig.1

Ensure when building your fire into the surround that the front glass

can be removed at all times. (Refer to 'Lamp Replacement section')

As when this is removed it allows the customer to change the bulbs

and in the unlikely event that a service engineer needs to access

the interior components of the fire.
The fire is fixed from the rear. The 4 fixing brackets need to be fixed

to the rear of the fire, using the screws provided. There are slots in

these brackets to allow for adjustment of the fire in position. Please

use 4 suitable wood screws to firmly fix the fire to the surround.

Controls

 - see

Fig. 2

Manual & Remote Operation.
The Standby switch must first be turned 'ON' to operate the fire

manually or by remote control.
To turn the flames on, press the

I

 button.

To turn the flames off, press the

O

 button.

To increase or decrease the brightness of the flames, use the

dimmer button   or the buttons on the Remote Control.

To turn off the power the Standby Switch must be turned 'OFF'.

Remote control

 - see

Fig. 7

The maximum range of use is ~ 15metres.
For details on the function please refer to the 'Controls' section in

this instruction leaflet.

Warning: It takes time for the receiver to respond to the transmitter.

Do not press the buttons more than once within two seconds for

correct operation.

Battery information

- see

 Fig. 7

1.Slide open the battery cover on the back of the remote control
2.Install AAA batteries into the remote control
3.Replace the battery cover.

Discard leaky batteries.
Dispose of batteries in the proper manner according to provincial

and local regulations.
Any battery may leak electrolyte if mixed with a different battery

type, if inserted incorrectly, if all the batteries are not replaced at the

same time, if disposed of in a fire, or if an attempt is made to charge

a battery not intended to be recharged.

Maintenance

WARNING: ALWAYS DISCONNECT FROM THE POWER

SUPPLY BEFORE ATTEMPTING ANY MAINTENANCE.

Lamp Replacement

 - see

Fig. 3

,

Fig. 4

 and

Fig. 5

To gain access to the lamps first slide the outer glass up using the

suction cups and then lift the glass out from the bottom and slide it

out (

Fig. 3

).

Warning: The fuel effect is fragile, and should be handle with due

care.
Remove the fuel effect from the fire by removing the fixing screws

from the fuel bed and the 9-way connector and the fuel bed will slide

out of the fire. (

Fig. 4

).

Remove the rotisserie by carefully sliding the rubber connector off

the motor shaft. (

Fig. 5

)

Remove the defective lamp by unscrewing it as shown in (

Fig. 5

).

Replace with a 60W E14 SES Clear Candle lamp.
Take care not to over-tighten the lamp.
Refit the rotisserie, fuel bed and the outer glass.

Suction Cups

 - see

Fig. 6

Place the suction cups onto the outer glass and close the handles

together as shown in (

Fig. 6

).

Recycling

For electrical products sold within the European Community.

At the end of the electrical products useful life it should

not be disposed of with household waste. Please

recycle where facilities exist. Check with your Local

Authority or retailer for recycling advice in your country.

After Sales Service

Should you require after sales service or should you need to

purchase any spares, please contact the retailer from whom the

appliance was purchased or contact the service number relevant to

your country on the warranty card. Please do not return a faulty

product to us in the first instance as this may result in loss or

damage and delay in providing you with a satisfactory service.

Please retain your receipt as proof of purchase.

Important Safety Advice:

When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electrical shock
and injury to persons, including the following:
If the appliance is damaged, check with the supplier before
installation and operation.
Do not use outdoors.
Do not use in the immediate surroundings of a bath, shower
or swimming pool.
Do not locate the appliance immediately below a fixed
socket outlet or connection box.
This appliance is not intended for use by children or other
persons without assistance or supervision if their physical,
sensory or mental capabilities prevent them from using it
safely. Children should be supervised to ensure that they do
not play with the appliance.
In the event of a fault unplug the appliance.
Unplug the appliance when not required for long periods.
The appliance must be positioned so that the plug is
accessible.
If the supply cord is damaged it must be replaced by the
manufacturer or service agent or a similarly qualified person
in order to avoid a hazard.
