Kapro 873G - Инструкция по эксплуатации - Страница 10

10

OPERATING INSTRUCTIONS

Working in Automatic mode (self-leveling):

In automatic mode the laser level will level itself in the range of ± 3°

and will project horizontally or vertically or all 3 beams simultaneously.

1. Remove the laser from the case and place it on a solid flat

   Vibration free surface or on a tripod.
2. Turn the locking switch #1 clockwise to  the

ON

 position.

  The laser level will generate horizontal and vertical beams

  forward, and  additional orthogonal side vertical beam. The
  green LED near the

V/H

 push button will light up.

3. The laser will generate cross beams forward and cross

  beams upward above the laser when all beams are activated.

4. Choose the beams that you want to work with by pushing the
  Beam push button

V/H

5. Use the adjustable metal legs #2 to adjust the height of the

   horizontal beam.

6. If the initial level of the laser is beyond ± 3° and the automatic

  mode is activated the laser beams will flash and a beeping alarm

  will be heard. In this case reposition the laser on a more level

 surface.

7. Before moving the laser level switch the locking switch #1 to
 the

OFF

 position this will lock the pendulum and protect

  your laser.
