7

Indirect measurement

Pythagorean measurement is used in the condition that the

objective needing to be measured is covered or has no effec-

tive reflecting surface and can’t be measured directly.

Make sure you adhere to the prescribed sequence of mea-

surement:

All target points must be in a horizontal or vertical plane.

The best results are achieved when the instrument is rotated

about a fixed point (e.g. with the positioning bracket fully fold

-

ed out and the instrument placed on a wall) or the instrument

is mounted on a tripod.

It is possible to use minimum / maximum function. The mini-

mum value must be used for measurements at right angles to

the target; the maximum distance for all other measurements.

Indirect measurement – determing a distance using 2

auxilary measurements.

E.g. When height and distance can’t be measured directly.

Press button (5) 3 one time. The symbol        is displayed.

The distance to be measured is blinking in the symbol tri-

angle.

Press button (4) to take distance measuring        . The result

is displayed in the first line.

Press button (4) to take distance measuring.

After  pressing  button  (4)  the  result  is  displayed  in  the  first

line. The result of the function        is displayed in the second

line.

Indirect measurement – determing a distance using 3

measurements.

Press button (5) 2 times. The symbol   is displayed. The

distance to be measured is blinking in the symbol triangle.

Press button (4) to take distance measuring     (side of the

triangle). The result of the function is displayed in the sec-

ond line.

Press button (4) to take distance measuring     (height of

the triangle) . The result of the measurement is displayed

in the first line.
