Oursson RF0480/DC - Инструкция по эксплуатации - Страница 14

14

TRANSPORTATION

, Рiс

. E

•

Make sure there are no children or animals in the

device.

•  Move  and  transport  the  device  only  in  the  un

-

loaded condition.

•  It is recommended to move and place the device

in two, Pic. E-1

•  Pack the device before moving it.

•  When  moving  do  not  grab  or  pull  the  door  or  door’s

handle.

•  When moving the device you cannot tilt it more than on

45 degrees. Protect the device from excessive vibration

and hits. Pic. E-2.

•  Please transport the device packed and in vertical po

-

sition. Improper transportation may result in injury and

damage of the device.

POSSIBLE PROBLEMS AND SOLUTIONS

Possible problems

Possible causes

Solutions

D

evice isn’t working.

•  There is no voltage in the mains.

•  The cord is plugged incorrectly.

•  Turn on the device.

•  Check the main and the plug. If they are

working, call the service center.

Vibrating noise .

The device is in unstable position.

•  Adjust the position of the device.

•  Move it if necessary.

The temperature is not cold
enough

•  The door is not closed firmly.

•  Not enough ventilation

•  Make sure the door is firmly closed.

•  Clean the vents.

The compressor is operating for
a long period.

•  Ambient temperature is too high.

•

The door is opened too often or
remains open.

•

Adjust the temperature of the room.

•  Make sure the door is firmly closed.

Frost accumulated on the rear

side of the device.

•

There is hot or moisture food in

the device.

•  High humidity of the

environment.

•

Do not place hot or unpacked products into the

device.

•  Adjust the humidity in the room.

Please check the possible problems before contacting a service center.

Reversing the door,

Pic D-4

1

2

3

4

5

6

7

8

Top hinge cover

Top hinge screw
Top hinge

Cabinet plug

Bottom hinge
Door handle plug
Bottom hinge screw

Leveling leg

1.

Remove top hinge cover

1

 and top hinge screws

2

which are below it. Then remove top hinge

3

 .

2.

Remove cabinet plugs

4

 and door handle plug

6

.

3.

Remove the door.

4.

Remove right and left leveling legs

8

.

5.

Remove the bottom hinge

5

 and bottom hinge screws

7

.

6.

Install the bottom hinge

5

 on the other side of the lev

-

eling legs with bottom hinge screws

7

.

7.

Install  right  and  left  leveling  legs

8

. There are two

holes below the refrigerator to fit the two levelling legs.

8.  Install the door.
9.  Install the top hinge

3

 on the other side with top hinge

screws

2

.

10.

Install  top  cover

1

  above  the  top  hinge  and  install

cabinet plugs

4

 and door handle plug

6

 on the other

side.

11.

Adjust the leveling legs

8

.

Note:

  Don’t  tilt  the  appliance  over  45°  when  revising  the

door as possible damage to the sealed system may occur.

CLEANING AND  MAINTENANCE,

Рiс. F

•  Unplug the device.

•  Wash the inner parts of the device with a soft cloth and

clean water with a detergent, then wipe everything with

a cloth and clean water and wipe dry.

•

Contamination of the door gasket can cause damage

to  it,  so  regularly  clean  it  with  a  soft  cloth  and  a  small

amount of neutral detergent.

•  Outer  surface  of  the  device  must  be  cleaned  with  a

slightly damp or dry cloth.

•  Do  not  rub  with  detergent  the  informational  sticker  in

-

side  the  device,  because  printed  information  can  be

erased. The information is necessary for service.

•

Do not spill water on the electrical components of

the device, as well as air vents because of the dan

-

ger of electric shock.
