Using the freezer compartment

EN

A

B

NO FROST

S

C

USING THE FREEZER COMPARTMENT

The freezer has two distinct compartments:

-   The top drawer “A” is used for freezing fresh food.
-    The lower and centre drawers “B” are used exclusively

for storing frozen food.

Prepare the food to be frozen in small portions (max 1 kg

for ease of freezing and eventual thawing. Wrap the food

in purpose-made polythene or aluminium foil, if possible

airtight. Make a note of the date of freezing on the wrap

and place it in the freezer drawer.

-  After the freezer has been started, approximately 3

hours are required for it to reach the correct tem-

perature for storing frozen food.

SETTING THE TEMPERATURE

The freezer compartment can also operate independently

from the fridge. To start the freezer, press button C for

at least 0.5 seconds. To stop the freezer, press button C

for at least 4 seconds until the display indicates “-- --”.
To set the required temperature, press button C. The

temperature initially set on the display will flash for 6

seconds. While the display is flashing, the required tem-

perature can be set by re-pressing button C. Each time

the button is pressed, the temperature will be varied by

one degree. Once the temperature is set, the display will

flash for 6 seconds, after which the actual temperature

of the compartment will appear.
The display indicates actual internal temperature values

between +20°C and -40°C.
Actual temperatures above +20 are signalled on the

display by the letter H.

FREEZER TEMPERATURE ALARM

The freezer has two types of alarm, audio and visual

(with a flashing display as shown in the figure). Both are

activated together when the temperature in the freezer

reaches a value higher than -12 (Example -11).
To silence the audible alarm, press the “super” button S.
The visual alarm will deactivate automatically when the

temperature returns to - 12.

WARNING: The first time the appliance is switched

on, the alarm will be activated automatically in that

the temperature in the freezer compartment is higher

than - 12.

FREEZING FRESH FOOD

The freezer compartment

  can be used to freeze

fresh food.
The quantity of fresh food freezable in 24 hours is indi-

cated on the appliance identification plate (see paragraph

“Electrical connection”).

Procedure:
-  Wrap the food in aluminium foil, transparent film,

plastic waterproof containers, polyethylene containers

with lids or purpose-made freezer containers.
