polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.  It  must  be  outside  the  area  of  the  rear  of  the

appliance.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

u

Press On/Off button

 Fig. 3 (1).

w

The  appliance  is  switched  on.  The  temperature  display  and

the  alarm  button  flash  until  the  temperature  is  sufficiently

cold.

5 Control

5.1 Door alarm

If the door is open longer then 60 s, the audible alarm sounds.
The  audible  alarm  is  automatically  silenced  when  the  door  is

closed.

5.1.1 Muting the door alarm

The  audible  alarm  can  be  muted  when  the  door  is  open.  The

sound  switch-off  function  is  active  as  long  as  the  door  is  left

open.

u

Press alarm button

 Fig. 3 (5).

w

The door alarm is silenced.

5.2 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The alarm button flashes at the same time.
The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  button

Fig.  3  (5)  goes  out  and  the  temperature  display  stops  flashing

when the temperature is sufficiently cold again.

If the alarm status persists: (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

5.2.1 Muting the temperature alarm

The  audible  alarm  can  be  muted.  When  the  temperature  is

sufficiently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 3 (5).

w

The audible alarm is silenced.

5.3 Freezing food

The maximum load of frozen food for the drawers is 25 kg each

and for the shelves 35 kg each.

CAUTION

Risk of injury due to broken glass!

Bottles  and  cans  containing  drinks  may  burst  when  being

frozen. This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In  order  that  the  food  is  rapidly  frozen  through  to  the  core,  do

not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.4 Storage life

Standard values for the storage life of various types of

food:

Ice-cream

2 to 6 months

Sausage, ham

2 to 6 months

Bread, bakery products

2 to 6 months

Game, pork

6 to 10 months

Fatty fish

2 to 6 months

Lean fish

6 to 12 months

Cheese

2 to 6 months

Poultry, beef

6 to 12 months

Vegetables, fruit

6 to 12 months

The values indicated for storage life are standard ones.

5.5 Thawing food

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.6 Setting the temperature

Temperature setting to be recommended: -18 °C
The  temperature  can  be  changed  continuously.  Once  the

-32 °C setting is reached, it starts again with -15 °C.

u

To  access  temperature  adjustment:  press  setting  button

Fig. 3 (2) once.

w

The  LED  of  the  current  temperature  flashes  in  the  tempera-

ture display.

Control

7
