4.2 Installing the appliance

In the event that the appliance is damaged, contact the supplier

immediately before connecting to the mains.
The floor at the site must be flat and level.
Do not install the appliance in a location where it is exposed to

direct radiation of the sun, next to a cooker, heater and similar.
Do not install the appliance without assistance.
Standard  EN  378  specifies  that  the  room  in  which  you  install

your  appliance  must  have  a  volume  of  1  m

2

  per  8  g  of  R  600a

refrigerant used in the appliance. If the room in which the appli-

ance  is  installed  is  too  small,  a  flammable  gas-air  mixture  may

form  in  the  event  of  a  leakage  in  the  refrigeration  circuit.  The

quantity of refrigerant used in your appliance is indicated on the

type plate on the inside of the appliance.
Fit the appliance in stable kitchen units only.
The following ventilation gaps must be observed:

q

The  depth  of  the  ventilation  channel  at  the  rear  of  the  unit

must be at least 38 mm.

q

There must be a ventilation space of at least 200 cm

2

 in the

plinth and at the top of the unit.

q

Basically  the  principle  applies:  the  larger  the  ventilation

space, the more energy-saving the appliance is in operation.

WARNING

Fire hazard due to dampness!

If  live  parts  or  the  mains  lead  become  damp  this  may  cause

short circuits.

u

The appliance is designed for use in enclosed areas. Do not

operate  the  appliance  outdoors  or  in  areas  where  it  is

exposed to splash water or damp conditions.

WARNING

Fire hazard due to refrigerant!

The  refrigerant  R  600a  is  environmentally  friendly  but  flam-

mable. Escaping refrigerant may ignite.

u

Do not damage the piping of the refrigeration circuit.

WARNING

Fire hazard and danger of damage!

u

Do  not  place  appliances  emitting  heat  e.g.  microwaves,

toasters etc. on the appliance!

u

Detach the connecting cable from the rear of the appliance,

removing  the  cable  holder  at  the  same  time  because  other-

wise there will be vibratory noise!

After installation:

u

Remove all transit supports.

u

Unscrew  the  red  transport

lock.  Close  the  vacated

retaining  hole  using  the

stopper (60).

u

Dispose of packaging material (see 4.3) .

If  the  appliance  is  installed  in  a  very  damp  environment,

condensate may form on the outside of the appliance.

u

Always see to good ventilation at the installation site.

4.3 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.4 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.

u

Check the electrical connection.

u

Clean the appliance (see 6.2) .

u

Plug in the power plug.

4.5 Switching on the appliance

Put  the  appliance  into  operation  about  2  hours  before  first

loading food to be frozen.
Do  not  load  food  to  be  frozen  before  the  temperature  display

reads -18 °C.

u

Press On/Off button

 Fig. 2 (4).

w

The  temperature  display  flashes  until  the  temperature  is

sufficiently  cold.  If  the  temperature  is  above  0  °C,  dashes

flash. If it is below, the set temperature flashes.

5 Control

5.1 Brightness of the temperature

display

You can adjust the brightness of the temperature display to the

light conditions of the room in which the appliance is installed.

5.1.1 Adjusting the brightness

The  brightness  is  adjustable  between

h1

  (no  illumination)  and

h5

 (maximum luminosity).

u

To  activate  the  setting  mode:  press  the  SuperFrost  button

Fig. 2 (5) for about 5 s.

w

The display indicates

c

.

w

The SuperFrost button flashes.

u

Using  the  Up  setting  button

  Fig.  2  (3)  or  Down  setting

button,

 Fig. 2 (2), select

h

.

Control

4
