12

-  Is the appliance switched on?

-  The bulb is defective. Change the bulb as described in "Inte-

rior light".

Interior light on when Cool-Plus activated:

-  This is necessary from a technical point of view and is

quite normal.

-  To be able to ensure that the Cool-Plus function works en-

tirely as it should, the defective light bulb should be replaced

as soon as possible.

Appliance does not work:

Your appliance is designed and manufactured for a long life

span and reliable operation.

If a malfunction nonetheless occurs during operation, check

whether it is due to an operating error. Please note that even

during the warranty period the resultant servicing costs in this

case will have to be borne by the owner.

You may be able to rectify the following faults by checking the

possible causes yourself:

Malfunction

Possible cause and remedy

5  Troubleshooting

Loud running noise:

-   Is the appliance standing firmly on the floor, or does the com-

pressor cause nearby items of furniture or objects to vibrate?

If necessary, move the appliance slightly, align by adjusting

the adjustable feet, or move bottles and containers apart.

-

Burbling noises

 are normal. These are caused by the refriger-

ant flowing round the refrigerant circuit.

  A short

clicking sound

: This will be heard whenever the refrig-

eration unit (the motor) switches on or off automatically.

  Motor noise:

 This will be slightly louder for a brief period

when the refrigeration unit switches on.

The temperature is not cold enough:

-  Is the temperature setting correct? If necessary, set a lower

temperature.

-  Loose thermometer in appliance is showing a wrong reading.

-  Does the door close properly?

-  Is the appliance sufficiently well ventilated? Clear ventilation

grilles if necessary.

-  Is the ambient temperature too hot? (See "Safety regulations")

-  Has the appliance been opened too often or left open too long?

-  If applicable, wait until the appliance reaches the required

temperature itself.

Customer service and type plate

If none of the above causes apply and you cannot

rectify the fault yourself, please contact your nearest

customer service department (see enclosed list for

addresses). State the

type designation

1

, service number

2

 and

appliance number

3

 as given on the type plate, so

as to ensure rapid, accurate servicing. The type plate is located

inside the appliance on the left-hand side.

-   Is the appliance switched on properly?

-   Is the mains plug properly inserted in the socket?

-   Is the socket fuse intact?
The interior light does not come on:

4  Defrosting, cleaning

Defrosting

The refrigerator compartment

defrosts automatically. The defrost water is evaporated

by the heat from the compressor; drops of water on the

rear wall are perfectly normal.

W

  Ensure that the defrost water can flow freely through the

drain hole in the rear wall (arrow in fig.

A

).

The freezer compartment

After a long period of operation, a layer of frost or ice can

build up inside the freezer compartment.

W

  To defrost, switch off the appliance:

-  Disconnect the appliance from the mains or

-  set the temperature control to "0".

W

  If possible, put the frozen goods in the freezer drawer, wrap

in newspaper or a blanket and store in a cool place.

W

  To speed up the defrosting process place a saucepan of hot

but not boiling water on one of the middle shelves.

  Do not use electric heaters or steam clean-ers, defrost-

ing sprays or naked flames for defrosting nor any metal

objects for removing the ice. Risk of injury and damage!

W

  Leave the appliance door open when defrosting.

  After defrosting, mop up the remaining water with a sponge

or cloth and clean the appliance.

Cleaning

W

  Before cleaning, always switch off the appliance.

Disconnect from the mains or un-screw or switch

off the fuse.

W

Wash shelves, glass plates and other options by hand.

W

  Clean the outer walls, inside and equipment by hand with

lukewarm water and a little detergent. Because of the risk of

injury and damage to the appliance, steam cleaning equip-

ment should not be used.

W

Do not use abrasive sponges or scourers, do not use

     concentrated cleaning agents and never use cleaning

     agents containing sand, chloride or acid or chemical sol-

vents, as these would damage the surfaces and could cause

corrosion.

W

We recommend using a soft cloth and an all-purpose cleaner

with a neutral pH value. Only use food safe cleaning materi-

als inside the appliance.

W

  For stainless-steel appliances*:

-    Clean the side panels and door surfaces with a clean and

soft cloth. If necessary, use a moist cloth (water + deter-

gent). Alternatively, use a micro-fibre cloth.

W

  Ensure that no cleaning water penetrates into the electrical

components, drain gulley* or ventilation grilles.

  Wipe the appliance dry.

W

  Do not damage or remove the type plate on the inside of the

appliance. It is very important for servicing purposes.

W

  Clean the

drain hole

 on the rear wall above the vegetable

bins frequently, fig.

A, arrow.

  If necessary, clean with a thin object, e.g. a cotton

swab or similar.

W

  Ensure that none of the wires or other components are dis-

lodged, bent or damaged.

W

  Then connect/switch on the appliance.

If the appliance is to be

left switched off for any length of

time

, empty the appliance, disconnect from the mains, clean

as described above and leave the door open so as to avoid

odours.

* Depending on model and options
