Kraft KF-NF720XD - Инструкция по эксплуатации - Страница 15

28

29

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE

ХОЛОДИЛЬНИК

 REFRIGERATOR-FREEZER

ХОЛОДИЛЬНИК

 REFRIGERATOR-FREEZER

Key technical data

Model

KF-NF720GD

Total Gross Volume (l)

456

Total Storage Volume (l)

432

Gross Refrigerator Volume (l)

337

Refrigerator  Storage Volume (l)

324

Gross Freezer Volume (l)

119

Полезный объем морозильной камеры (л)

108

Compressor Type & Number

Hermetic/1

Refrigerant

R600a

Frother

C-Pentane

Defrost

No Frost

Power Voltage (V / Hz)

220-240 / 50

Power Input (watt)

103

Temperature Control

LED display

Energy Class

SN/N/ST/T

Energy Consumption (kWh/year)

285

Climate Class

A++

Noise Level dB(A)

43

Number of Cooling Chambers / Number of Doors

2/2

Evaporator Type

inside

Handle Type

Recessed

Reverse door

yes

Specification of Refrigerating Chamber

Defrost

No Frost

Interior Lamp (name)

LED lamp

Adjustable shelf type / number

2

Crisper cover type / number

2

Crisper Drawer Material / Number

2

Door Balcony Material / Number

4

Egg tray

1

Specification of Freezer Compartment

Max low temperature

-24

Freezing Capacity

5 kg/24h

Evaporator Type

inside

Defrost

No Frost

Number of drawers

3

Ice tray

1

Total Dimensions

Dimension Product (mm)

703x703x1855

Dimension Package (mm)

750x756x1920

Weight (kg) Net / Gross

83/91

Equipment

Refrigerator-Freezer

1 pc

User Guide

1 pc

Packaging

1 pc

How to save energy

01. Install the refrigerator in the coolest part of the room, out of direct sunlight and away

from heating ducts or registers. Do not place the refrigerator next to heat-producing
appliances such as a range, oven or dishwasher.

02. The refrigerator door should remain open only as long as necessary; do not place hot

food inside the refrigerator.

03. Organize the refrigerator to reduce door openings .Remove as many items as needed

at one time and close the door as soon as possible.

04. The  refrigerator  door  should  be  properly  closed  to  avoid  increased  energy

consumption, and the formation of excess ice and / or condensation inside.

05. Constantly  circulating  cold  air  keeps  the  temperature  homogenous  inside  the

refrigerator. For this reason, it is important to properly distribute the food, to facilitate
the flow of air.

06. Cover foods and wipe containers dry before placing them in the refrigerator. This cuts

down on moisture build-up inside the unit.

07. Do  not  overcrowd  the  refrigerator  or  block  cold  airvents.  Doing  so  causes  the

refrigerator  to  run  longer  and  use  more  energy.  Shelves  should  not  be  lined  with
aluminum foil, wax paper or paper toweling. Liners interfere with cold air circulation,
making the refrigerator less efficient, which could cause food spoilage.

08. During  prolonged  absences  (example:  vacations),  it  is  advisable  to  disconnect  the

refrigerator, remove all the food, and clean it . The door should be left slightly open
to  avoid  mold  and  unpleasant  odors.  This  will  not  affect  the  refrigerator  when  it  is
reconnected.

09. During short absences (example: holidays), the refrigerator can remain on. However,

remember that prolonged power outages may occur while you are gone.

Servicing

•  This product should be serviced by an authorized engineer and only genuine spare

parts should be used.

•  Under no circumstances should you attempt to repair the appliance yourself.
•  Repairs  carried  out  by  inexperienced  persons  may  cause  injury  or  serious

malfunctioning. Contact the local store where your purchase was made.

•  When  the  appliance  is  not  in  use  for  long  periods,  disconnect  from  the  electricity

supply,  empty  all  foods  and  clean  the  appliance,  leaving  the  door  ajar  to  prevent
unpleasant smells.

Trouble shooting

The  following  simple  issues  can  be  handled  by  the  user.  Please  call  the  after-sale

service department if the issues are not settled.

Power cut

If  the  internal  temperature  of  the  Fridge/Freezer  compart-

ment  is  -18°C  or  less  when  the  power  returns,  your  food

is safe. The food in your Fridge/Freezer will remain frozen

for approx 16 hours with the door closed. Do not open the

Fridge/Freezer door more than necessary.
