18

1   Freezer light

2   Freezer shelf

3   Ice cube maker

1) Do not overfill this tray with water.

Otherwise the ice cubes will join

together when frozen.

2) When ice cubes are made, turn the

lever clockwise to put the ice into the

Ice cube box.

4   Ice cube box

Note

To prevent the ice cube box from being damaged, do

not pour oil into the box or make ice in it.

5   Fresh case & door

6   Control panel

7   Deodorizing unit

Deodorizing catalyst is installed on the routes of cold

air. There is no need to operate and clean.

8   Refrigerator light

9   Smooth access shelf

You can pull out this shelf.

10   Refrigerator shelf

SJ-XE55PM : 1 pc

SJ-XP59PG, SJ-XE59PM : 2 pcs

11   Hybrid cooling panel

The panel cools the refrigerator compartment

indirectly from the rear. In this way, food is cooled

gently without being exposed to cold air flow.

12   Fruit and vegetable shelf

13   Fruit and vegetable crisper

(2 pcs)

14   Adjustable foot

(2 pcs)

15

Caster

 (4 pcs)

The casters allow the refrigerator to

move back and forth.

16   Foot cover

17   Magnetic door seal

(2 pcs)

18   Freezer door pocket

(2 pcs)

19   Egg holder

20   Egg pocket

SJ-XE55PM : 2 pcs

SJ-XP59PG, SJ-XE59PM : 1 pc

21   Refrigerator pocket (Upper)

(Only for SJ-XE59PM)

22   Bottle pocket

23   Refrigerator pocket (Bottom)

More food can be stored by taking out the

internal accessories with normal cooling

operation

You may remove following

accessories.

  2

Freezer shelf

  3

Ice cube maker

  4

Ice cube box

  5

Fresh case & door

  9

Smooth access shelf

10

Refrigerator shelf

13

Fruit and vegetable crisper

Lever

Ice cube box

Description

SJ-XP59PG

1

2

3

4
5

7

8

9

10

11
12
13
15

14
16

17
18
6
18

19
20

21

22

23

17

14

SJ-XE55PM, SJ-XE59PM

17
18

18

19
20

21

22

23

17

14

1

2

3

4
5

7

8

6

9

10

11
12
13
15

14
16

Casters

20
20

SJ-XE55PM
