17

ENGLISH

1

  Keep adequate ventilation space around the

refrigerator.

• The figure shows the

minimum required

space for installing

the refrigerator. The

measurement condition

of power consumption

is conducted under

a different space

dimension.

• By keeping greater space, the refrigerator may

consume a less amount of power consumption.

• If use the refrigerator in the smaller space

dimension than figured, it may cause temperature

rise in the unit, loud noise and failure.

• The space between the rear of the refrigerator and

the wall should be 60mm or more, and less than

75mm.

If the space is wider than 75mm, you may get

injured by touching compressor and its peripheral

parts which are extremely hot during the operation.

Overall space required in use

Installation

Free standing type

90mm

or more

60mm

or more

60mm

or more

1525 mm

1420 mm

2

  Turn the two adjustable feet of the front side to make

the spaces to insert the foot supports.

(The foot supports are packed inside

the refrigerator compartment.)

After inserting the supports,

adjust the two feet to stabilize

the refrigerator.

• The refrigerator is slightly tilted backward by

inserting the supports. It is effective to install the

refrigerator firmly.

3

  Remove the 2 screws of the lower part of the cabinet

and use these screws to set the foot cover.

(The foot cover is packed inside the refrigerator

compartment.)

Adjustable foot

Foot support

Ԙ

Ԙ

ԙ

ԙ

Foot cover

Screw

(2 screws)

Note

• Place your refrigerator to access the plug.

• Keep your refrigerator out of direct sunlight and do not

place next to heat generating appliance.

• Do not place your refrigerator directly on the ground.

Insert suitable stand such as wooden board under the

refrigerator.

• When you insert the power plug with the door opened,

door alarm sounds but it is not abnormal. This sound

stops after closing the door.

Before using your refrigerator

Clean the inside parts with a cloth soaked in warm water.

If soapy water is used, wipe it off thoroughly with water.
