8

INSTALLATION

 1.

This refrigerator is free standing type. Please keep

adequate ventilation space around the refrigerator.

•

The figure shows minimum space necessary to

maintain the cooling capability.

•

It is possible to use the refrigerator with a less amount

of power consumption by keeping greater space.

•

If using the refrigerator in the space below size of the

figure, it becomes cause of failure.

 2.

Using the front Adjustable foot, ensure that the

refrigerator is positioned firmly and level on the floor.

NOTE:

•

Position your refrigerator so that the plug is accessible.

•

Keep your refrigerator out of direct sunlight.

•

Do not place next to heat generating appliance.

•

Do not place directly on the ground. Provide suitable

stand.

Before using your refrigerator

Clean the inside parts with a cloth soaked in warm water.
If soapy water is used, wipe it off thoroughly with water.

OPERATION

Controlling temperatures

•

FREEZER TEMP. CONTROL regulates the quantity of

cold air to the freezer.

•

If the freezer does not cool even when setting FREEZER

TEMP. CONTROL to MAX, set REFRIGERATOR TEMP.
CONTROL to MAX as well.

•

With FREEZER TEMP. CONTROL set to MAX, there will be

less cold air directed to the refrigerator compartment, and
the refrigerator compartment may not become cold enough.

•

REFRIGERATOR TEMP. CONTROL controls the

compressor running time of the refrigeration system.

•

MAX setting will result in colder temperature in the both

(refrigerator and freezer) compartments.

•

The freezer compartment may not cool sufficiently when

leaving REFRIGERATOR TEMP. CONTROL as MIN for an
extensive period. To cool the freezer compartment properly,
set REFRIGERATOR TEMP. CONTROL closer to MAX.

Over 35°C ambient temperature

Under 10°C ambient temperature

Hints when making ice

1.

Do not over fill the Ice cube trays;

otherwise the ice cubes will be
joined together when frozen.

2.

When the ice cubes are made, turn

the lever clockwise to empty the ice
into the Ice cube box.

NOTE:

To prevent damage to the Ice cube
box, do not make ice in the Ice cube
box or pour oil into it.

Deodorizing unit

Deodorizing catalyst is installed on the routes of cold air.
No operation and cleaning are required.

Defrosting

Defrosting is fully automatic due to a unique energy saving
system.

a

b

Adjustable

foot

This is because MAX setting (FREEZER TEMP.
CONTROL) may result in too little air flow to the
refrigerator compartment, causing too warm temperature
in the refrigerator compartment.

If the foods in the
refrigerator compartment
freeze.

This is because the
compressor operation is too
short in winter, and not
enough cold air is provided
to the freezer compartment.

Lever

Ice cube box
