EN - 37

•

Your appliance is designed to operate in

the ambient temperature (T/SN = 10°C

- 43°C) intervals stated in the standards,

according to the climate class displayed

on the information label. We do not

recommend operating your appliance out

of the stated temperature limits in terms

of cooling effectiveness.

Climate

Class

Ambient Temperature

o

C

T

Between 16 and 43  (°C)

ST

Between 16 and 38  (°C)

N

Between 16 and 32  (°C)

SN

Between 10 and 32  (°C)

Important installation instructions

This appliance is designed to work in

difficult climate conditions (up to 43

degrees C or 110 degrees F) and is

powered with ‘Freezer Shield’ technology

which ensures that the frozen food in the

freezer will not defrost even if the ambient

temperature falls as low as -15 °C. So

you may then install your appliance in an

unheated room without having to worry

about frozen food in the freezer being

spoilt. When the ambient temperature

returns to normal, you may continue using

the appliance as usual.

3.5 Temperature indicator

In order to help you better set your

refrigerator, we have equipped it

with a temperature indicator

located in the coldest area.

To better store the food in your

refrigerator, especially in the

coldest area, make sure the

message “OK” appears on the

temperature indicator. If « OK » does not

appear, this means temperature has not

been set properly

It may be difficult to see the indicator,

make sure it is properly lit.Each time the

temperature setting device is changed,

wait for the stabilisation of the temperature

inside the appliance before proceeding,

if necessary, with a new temperature

OK

setting. Please change the position of the

temperature setting device progressively

and wait at least 12 hours before starting a

new check and potential change.

NOTE:

 Following repeated openings

(or prolonged opening) of the door or

after putting fresh food into the appliance, it

is normal for the indication “OK” not to

appear in the temperature setting indicator.

If there is an abnormal build up of ice

crystals of ice crystals (bottom wall of the

appliance) on the refrigerator compartment,

evaporator (overloaded appliance, high

room temperature, frequent door openings),

put the temperature setting device on a

lower position until compressor off periods

are obtained again.

Store food in the coldest area of the

refrigerator.

Your foods will be better stored

if you put them in the most

appropriate cooling area. The

coldest area is just above the

crisper.

The following symbol indicates the coldest

area of your refrigerator.

To be sure to have a low temperature in this

area, make sure the

shelf is located at

the level of this

symbol, as shown in

the illustration.

The upper limit of

the coldest area

is indicated by the

lower side of the

sticker (head of the arrow). The coldest

area upper shelf must be at the same level

with the arrow head. The coldest area is

below this level.

As these shelves are removable, make

sure they are always at the same level with

these zone limits described on the stickers,

in order to guarantee temperatures in this

area.
