 English |

15

Bosch Power Tools

F 016 L70 763 | (24.5.11)

Continuous lighting

 of the

green charge control LED

signals that the battery is fully charged.
Additionally, a signal tone sounds for approx.

2 seconds, which acoustically indicates that the bat-

tery is fully charged.
Afterwards, the battery can be removed for immediate

use.
With no battery inserted,

continuous lighting

 of the

green charge control LED

 indicates that the mains

plug is plugged into the socket and that the battery

charger is ready for operation.

Battery Temperature below 0 ° C and
above 45 ° C

Continuous lighting

 of the

red LED

 indicates that the

battery temperature is not within the rapid-charging

temperature range of 0 ° C

–

45 ° C. As soon as the al-

lowable temperature range is reached, the battery

charger automatically switches to rapid charging.
When the battery is not within the allowable tempera-

ture range, the red battery LED lights up when insert-

ing the battery into the battery charger.

No charging procedure possible

If a different malfunction of the charging procedure is

present, this will be indicated through

flashing

 of the

red charge control LED

.

The charging procedure cannot be started and the bat-

tery cannot be charged (see section “Troubleshooting”).

Charging Advice

With continuous or several repetitive charging cycles

without interruption, the charger can warm up. This is

not meaningful and does not indicate a technical de-

fect of the battery charger.
A significantly reduced working period after charging in-

dicates that the battery is used and must be replaced.
Observe the notes for disposal.

Battery Cooling (Active Air Cooling)

The fan control integrated in the battery charger con-

trols the temperature of the inserted battery. When

the battery temperature is above 30 ° C, a fan cools

down the battery to the optimal charging temperature.

The switched-on fan produces a fan noise.
The battery temperature is within the optimal charging

temperature range when the fan is not running. Anoth-

er reason for a non working fan might be that it is de-

fective. In this case, the charging time of the battery

might be extended.

Working Advice

Battery Charge-control Indication

The battery  is equipped with a charge-control indica-

tor  which indicates its charge condition. The charge-

control indicator  consists of 3 green LEDs.
Press the button  to actuate the charge-control

indicator . After approx. 5 seconds, the charge-control

indicator goes out automatically.
The charge condition can also be checked when the

battery is removed.

When no LED lights up after actuating the button , the

battery is defective and must be replaced.
For safety reasons, the charge condition of the battery

can only be checked when the garden product is at a

standstill.
During the charging procedure, the three green LEDs

light up one after the other and briefly go out. The bat-

tery is fully charged when the three green LEDs light

up continuously. The three LEDs go out again approx.

5 minutes after the battery has been fully charged.

Temperature Control Indicator

The red LED  signals that the battery or the electronics

of the garden product (with battery inserted) are not

within the optimum temperature range. When this oc-

curs the garden product will not operate or not at full

capacity.

Temperature Control of the Battery

The red LED  flashes when pushing button  or pressing

the On/Off switch  (when the battery is inserted): The

battery is not wihin the temperature range for opera-

tion of

–

10 ° C to + 60 ° C.

The battery switches off at a temperature above 70 ° C

until the optimum temperature range is reached again.

Temperature Control of the Garden Prod-
uct Electronics

The red LED  lights up

continuously

 when pressing the

On/Off switch : The temperature of the garden product

electronics is below 5 ° C or above 75 ° C.
At a temperature above 90 ° C, the electronics of the

garden product switch off until the temperature is

within the allowable temperature range again.

Area of Cut (Battery Duration)

The area of cut (battery duration) depends on lawn

conditions, grass density, mositure content, grass

length and height of cut.
Switching the machine on and off frequently during

cutting will also reduce the area of cut (battery dura-

tion).
To improve the area of cut (battery duration) it is rec-

ommended to cut more frequently, raise the cutting

height and walk at a normal pace.
The example below shows impact of conditions

against run time, for one battery.

* with battery 2 607 336 107
To increase the run time an additional battery or high-

er capacity battery (Ah) can be purchased from an au-

thorised customer service agent for Bosch garden

products.

AL 3640 CV

Professional

AL 3620 CV

Professional

AL 3640 CV

Professional

AL 3620 CV

Professional

LED Indicators

Battery Capacity

Continuous lighting of 3 green LEDs

≥

2/3

Continuous lighting of 2 green LEDs

≥

1/3

Continuous lighting of 1 green LED

≤

1/3

Flashing of 1 green LED

Reserve

Cutting Conditions

Very light, dry

grass

Light, dry grass

Medium, dense

grass

Area of cut (Rotak 34 LI)*

up to 300 m

2

up to 150 m

2

up to 100 m

2

Area of cut (Rotak 37 LI)*

up to 300 m

2

up to 150 m

2

up to 100 m

2

Area of cut (Rotak 43 LI)*

up to 300 m

2

up to 150 m

2

up to 100 m

2

6cm

4cm

8cm

4cm

15cm

4cm
