Assembly
12
660 / 870III / 875III / 5001R
ASSEMBLY
WARNING!
Do not pour in engine oil and petrol until
after the assembly is complete!
Disconnect the spark plug connector be-
fore starting the assembly!
ASSEMBLY OF HANDLEBAR BRACKET
ON DECK
(1)
Handlebar bracket
(1-1)
Place the handlebar bracket on the deck and
screw it on.
(1-2)
Hex screw
M8 x 16
(2x)
(1-3)
Hex screw
M8 x 25
(2x)
Washer
∅
8 x 0
24 x 4
(2x)
ASSEMBLY OF HANDLEBARS ON
HANDLEBAR BRACKET
(2)
Handlebar
(2-1)
Unscrew and remove the fastening screws for the
handlebar on the handlebar bracket.
(2-2)
Round-head screw
M8 x 40
(2x)
(2-3)
Washer
∅
8.5 x
∅
24 x 4
(2x)
Nut
M8 self-
locking
(2x)
Screw handlebars onto handlebar bracket.
ASSEMBLY OF BLADE CARRIER
(3)
Blade carrier
(3-1)
Holding socket for blade carrier on deck
(3-2)
.
Slightly grease the holding socket and insert the
blade carrier.
Push the blade carrier fully in and insert the V-belt
into V-belt sheaves
(3-3)
.
WARNING!
The V-belt must run within the holding
pins.
ASSEMBLY OF RETURN SPRINGS (4)
1. Open clamping lever
(4-1)
.
2. Hook return springs
(4-2)
in on both sides of
machine
(4-3)
.
3. Clamp return springs, close clamping lever.
ASSEMBLY OF BOWDEN CABLES
(5)
Bowden cable travel drive (5-1)
Bowden cable scythe attachment (5-2)
Bowden cable accelerator adjustment (5-3)
Bowden cable accelerator adjustment
(6)
1. Set the throttle lever on the right handlebar to
the << START >> position.
2. Push regulator lever
(6-1)
on the carburettor
all the way to the left (= start position).
3. Hook the angled end of the Bowden cable
wire onto the regulator lever.
4. Insert the Bowden cable sleeve into terminal
(6-2)
under the clamping screw.
5. Pull the Bowden cable sleeve back slightly by
hand until you can feel resistance.
6. Clamp the Bowden cable sleeve in this posi-
tion.
WARNING!
Do not kink the Bowden cable during as-
sembly.
Bowden cable travel drive
(7)
The Bowden cable of the travel drive is on the
right
of the deck as seen in the direction of travel.
1. Insert the Bowden cable through the guide on
handlebar
(7-1)
.
2. Unscrew the front nut on adjustment part
(7-2)
.
3. Hook the adjustment part into the holder and
screw the nut back on.
4. Set the adjustment part at the bottom of the
housing approx. in the middle.
Bowden cable scythe attachment
(8)
1. The Bowden cable for the scythe attachment
is on the left of the deck as seen in the direc-
tion of travel.
2. Screw back both nuts on the upper adjust-
ment part of the Bowden cable all the way. To
do this, unscrew the front nut on the adjust-
ment part and take out of holder
(8-1)
.
3. Insert the Bowden cable through the guide on
handlebar bracket
(8-2)
.
