8 ENGLISH

Changing the impact force

►

Fig.8:

1.

 Hard

2.

 Soft

3.

 Changed in two steps

4.

 Pin hole

You can change the impact force in two steps: hard and

soft mode.

This allows a tightening suitable to the work.

Every time the pin hole is pressed, the number of blows

changes in two steps.

You can change the impact force within approximately

one minute after releasing the switch trigger.

Impact force grade displayed

on panel

Maximum blows

Purpose

Example of application

Hard

S H

3,900 min

-1

 (/min)

Tightening when force and

speed are desired.

Tightening wood screws,

tightening bolts.

Soft

S H

3,300 min

-1

 (/min)

Tightening with less force to

avoid screw thread breakage.

Tightening sash screws, tight-

ening small screws such as M6.

NOTE:

 When all lamps on the switch panel go out, the tool is turned off to save the battery power. The impact force

grade can be checked by pulling the switch trigger to the extent that the tool does not operate.

NOTE:

 While pulling the switch trigger, the impact force grade cannot be changed.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/socket bit

Optional accessory

►

Fig.9

Use only driver bit/socket bit that has inserting portion

shown in the figure. Do not use any other driver bit/

socket bit.

For tool with shallow driver bit hole

A=12mm

B=9mm

Use only these type of driver

bit. Follow the procedure

1. (Note) Bit-piece is not

necessary.

For tool with deep driver bit hole

A=17mm

B=14mm

To install these types of driver

bits, follow the procedure 1.

A=12mm

B=9mm

To install these types of driver

bits, follow the procedure 2.

(Note) Bit-piece is necessary

for installing the bit.

Procedure 1

To install the driver bit, pull the sleeve in the direction of

the arrow and insert the driver bit into the sleeve as far

as it will go.

Then release the sleeve to secure the driver bit.

►

Fig.10:

1.

 Driver bit

2.

 Sleeve

Procedure 2

To install the driver bit, pull the sleeve in the direction

of the arrow and insert the bit-piece and driver bit into

the sleeve as far as it will go. The bit-piece should be

inserted into the sleeve with its pointed end facing in.

Then release the sleeve to secure the driver bit.

►

Fig.11:

1.

 Driver bit

2.

 Bit-piece

3.

 Sleeve

To remove the driver bit, pull the sleeve in the direction

of the arrow and pull the driver bit out.

NOTE:

 If the driver bit is not inserted deep enough

into the sleeve, the sleeve will not return to its original

position and the driver bit will not be secured. In this

case, try re-inserting the bit according to the instruc

-

tions above.

NOTE:

 When it is difficult to insert the driver bit, pull

the sleeve and insert it into the sleeve as far as it will

go.

NOTE:

 After inserting the driver bit, make sure that it

is firmly secured. If it comes out, do not use it.

Installing hook

Optional accessory

The hook is useful to hang the tool. Install the hook to

the holes on the tool body.

►

Fig.12:

1.

 Hook

2.

 Hole
