7 ENGLISH

Indicating the remaining battery capacity

Only for battery cartridges with the indicator

►

Fig.2:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi

-

cate the remaining battery capacity. The indicator lamps

light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

75% to 100%

50% to 75%

25% to 50%

0% to 25%

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Switch action

►

Fig.3:

1.

 Switch trigger

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

To start the tool, simply pull the switch trigger. Tool

speed is increased by increasing pressure on the switch

trigger. Release the switch trigger to stop.

NOTE:

 The tool automatically stops if you keep pull

-

ing the switch trigger for about 6 minutes.

Electric brake

This tool is equipped with an electric brake. If the tool

consistently fails to quickly stop after the switch trigger

is released, have the tool serviced at a Makita service

center.

Lighting up the front lamp

CAUTION:

Do not look in the light or see the

source of light directly.

►

Fig.4:

1.

 Lamp

►

Fig.5:

1.

 Pin hole

Pull the switch trigger to turn on the lamp. To turn off,

release it. The lamp goes out approximately 10 seconds

after releasing the switch trigger.

To keep the lamp off, turn off the lamp status. First pull

and release the switch trigger. And then press the pin

hole for one second within 10 seconds.

To turn on the lamp status again, press the pin hole

again similarly.

NOTE:

 To confirm the lamp status, pull the trigger.

When the lamp lights up by pulling the switch trigger,

the lamp status is ON. When the lamp does not come

on, the lamp status is OFF.

NOTE:

 When the tool is overheated, the LED display

blinks for one minute, and then it goes off. In this

case, cool down the tool before operating again.

NOTE:

 Use a dry cloth to wipe the dirt off the lens of

the lamp. Be careful not to scratch the lens of lamp, or

it may lower the illumination.

Reversing switch action

►

Fig.6:

1.

 Reversing switch lever

CAUTION:

Always check the direction of

rotation before operation.

CAUTION:

Use the reversing switch only after

the tool comes to a complete stop.

 Changing the direc-

tion of rotation before the tool stops may damage the tool.

CAUTION:

When not operating the tool, always

set the reversing switch lever to the neutral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun-

terclockwise rotation.

When the reversing switch lever is in the neutral posi-

tion, the switch trigger cannot be pulled.

Remaining battery capacity

automatic stop function

If the remaining battery capacity is less than 30%, the

tool does not start even when you pull the switch trigger.

This is to prevent insufficient tightening.

When you pull the switch trigger just before the auto

-

matic stop function starts, the lamp blinks several times.

When you pull the switch trigger while the automatic

stop function works, the lamp also blinks. In these

cases, charge the battery or replace the battery with

fully charged one.

For battery cartridges with the remaining battery

capacity indicator, the automatic stop function can start

regardless of the state of remaining capacity display on

the battery.

►

Fig.7:

1.

 Switch trigger

2.

 Lamp
