20

 | English

LEDs

Capacity

1× flashing green light

0−5 %

Battery model ProCORE18V...

LEDs

Capacity

5× continuous green light

80−100 %

4× continuous green light

60−80 %

3× continuous green light

40−60 %

2× continuous green light

20−40 %

1× continuous green light

5−20 %

1× flashing green light

0−5 %

Inserting the

Bluetooth

® Low Energy Module

GCY 42 (Accessory)

Read the corresponding operating instructions for informa-
tion about the

Bluetooth

® Low Energy Module

GCY 42

.

Changing the Tool (see figures A–B)

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

u

When working with an application tool, pay attention
that the application tool is connected securely to the
tool holder.

 When the application tool is not securely

connected with the tool holder, it can come off during ap-
plication.

Slide the application tool

(10)

 onto the square drive of the

tool holder

(1)

.

Operation

Method of Operation

The tool holder

(1)

 (with the application tool) is driven by an

electric motor via a gear and impact mechanism.
The working procedure is divided into two phases:

Screwing in

 and

tightening

 (impact mechanism in action).

The impact mechanism is activated as soon as the screwed
connection runs tight and load is therefore put on the motor.
The impact mechanism then converts the power of the mo-
tor to steady rotary impacts. When loosening screws or nuts,
the process is reversed.

Starting Operation

u

Always place the power tool down on its side and do
not lay it on the battery.

 The power tool can tip over de-

pending on the application tool and battery used.

Inserting the battery
Note:

 The use of batteries unsuitable for your power tool can

lead to malfunctions or damage to the power tool.
Push the charged battery

(5)

 into the base of the power tool

until the battery is securely locked.

Set the rotational direction (see figure E)

The rotational direction switch

(2)

 is used to change the ro-

tational direction of the power tool. However, this is not pos-
sible while the on/off switch

(8)

 is being pressed.

Right rotation:

 To drive in screws and tighten nuts, press

the rotational direction switch

(2)

 through to the left stop.

Left Rotation:

 To loosen and unscrew screws and nuts,

press the rotational direction switch

(2)

 through to the right

stop.

Adjusting the Speed/Impact Rate

You can adjust the speed/impact rate of the power tool when
it is on by pressing in the on/off switch

(8)

 to varying ex-

tents.
Applying light pressure to the on/off switch

(8)

 results in a

low rotational speed/impact rate. Applying increasing pres-
sure to the switch increases the speed/impact rate.

Switching on/off

To

start

 the power tool, press and hold the on/off switch

(8)

.

The worklight

(15)

 lights up when the on/off switch

(8)

 is

lightly or fully pressed, allowing the work area to be illumin-
ated in poor lighting conditions.
To

switch off

 the power tool, release the on/off switch

(8)

.

User interface (see figures D–E)

GDS 18V-1000 C / GDS 18V-1050 HC:

The user interface

(7)

 is used to preselect the speed and

working mode and to indicate the status of the power tool.

Status indications

Status indicator for power
tool (11)

Meaning/cause

Solution

Green

Status OK

–

Yellow

Critical temperature has been reached or re-
chargeable battery is almost empty

Run the power tool at no load and allow it to
cool down, or replace or charge the battery
soon

Illuminated red

Power tool has overheated or rechargeable
battery is empty

Allow the power tool to cool down, or replace
or charge the battery
