ENGLISH

en

12

Feed direction

Always work in the opposite direction. Always push

the machine forwards as shown. See fig. B.
The direction of rotation of the cutter is indicated by

an arrow (13) on the machine.
Guide the machine evenly at a speed suitable for

the material being processed.

7.3 Putting down after use

After ending the cutting process, switch off the

machine and only set it down when the motor has

come to a standstill.

7.4 Special working methods:
Cutting with parallel guide (fig. C)

1. Attach the parallel guide (14) with screws (11) on

the machine.

2. Undo the wing screw (a) and adjust the distance

to the cutter. Tighten the wing screw (a).

Stop with guide bearings (see fig. D)

The stop with guide bearings (15) is used for cutting

along a curved edge
1. Attach the stop (15) with the screw (11) to the

machine.

2. Undo the clamping screw (a).

3. Using the adjusting screw (b), set the desired

distance to the cutter.

4. Tighten the clamping screw (a).

Template follower (see fig. E)

For cutting according to a template fixed on the

workpiece.
1. Undo the screws (a) to remove the footplate (8).

Insert the template follower (16) and then screw

the footplate (8) back on.

2. Attach a template (b) on the workpiece (c). Place

the machine on the template and guide it so that

the template follower (16) glides along the edge

of the template (b).

Milling along a strip attached to the workpiece

/ milling along a straight marking

1. Attach a strip on the workpiece and guide the

machine with a straight edge of the foot plate

along the strip. (Always use the same edge.)

Profile milling

1. When working with profile cutters, first remove a

larger chip and then a smaller chip.

2. The feed rate must not be too low, otherwise the

wood will scorch and the cutter will become

prematurely blunt.

Unplug power cable.

Dust deposits must be regularly removed from the

machine. This includes vacuum cleaning the

ventilation louvres on the motor.

Restart protection:

The machine does not start.

Restart protection is

active. If the mains plug is inserted with the machine

switched on or if the power supply is restored

following an interruption, the machine does not start

up. Switch the machine off and back on again.

Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.
For the complete range of accessories, see

www.metabo.com or the main catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

A defective mains cable must be replaced only with

a special, original mains cable from Metabo

available from the Metabo service.
Contact your local Metabo representative if you

have Metabo power tools requiring repairs. For

addresses see www.metabo.com.
You can download a list of spare parts from

www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.
Packaging materials must be disposed of according

to their labelling in accordance with municipal

guidelines. Further information can be found at

www.metabo.com in the “Service” section.

Only for EU countries: never dispose of

power tools in your household waste!

According to European Directive 2012/19/EU

on Waste from Electric and Electronic Equipment

and implementation in national law, used power

tools must be collected separately and recycled in

an environmentally-friendly manner.

Explanatory notes on the specifications on page 3.

Changes due to technological progress reserved.

P

1

= Rated  input

P

2

= Power output

n

0

= Idle  speed

n

1

= Speed at rated load

H

max

= max.  stroke  height

D

max

= max. permissible diameter of the cutter

m

= Weight without mains cable

Note:

The diameter of the collet bore of the collet

chuck can be found on the nameplate of the

machine.
Measured values determined in conformity with

EN 62841.

Machine in protection class II

8. Cleaning, Maintenance

9. Troubleshooting

10. Accessories

11. Repairs

12. Environmental Protection

13. Technical specifications
