Edge or profile routing (see figure F)

For edge and profile routing without a parallel guide, the
router bit must be fitted with a pilot pin or a ball bearing.
While it is switched on, guide the power tool towards the
workpiece from the side until the pilot pin or the ball bearing
of the router bit is touching the side of the workpiece edge
that you want to machine.
Guide the power tool along the workpiece edge. Pay atten-
tion that the router is positioned perpendicularly. Too much
pressure can damage the edge of the workpiece.

Routing with a parallel guide (see figure G)

You can fit a parallel guide

(19)

 for when cutting parallel to

an edge.
Fit the parallel guide

(19)

 to the routing base

(2)

 using the

nut

(4)

.

Set the desired stop depth using the wing bolt on the parallel
guide

(20)

.

While it is switched on, guide the power tool along the work-
piece edge with a uniform feed and while applying lateral
pressure to the parallel guide.

Routing with a pilot (see figure H)

The pilot

(21)

 helps when routing edges with router bits

without a pilot pin or ball bearing.
Fit the pilot to the routing base

(2)

 using the nut

(4)

.

Guide the power tool along the workpiece edge with a uni-
form feed.

Lateral clearance:

 To change the amount of material being

removed, you can adjust the lateral clearance between the
workpiece and the guide roller

(24)

 on the pilot

(21)

.

Loosen the wing bolt

(22)

, set the lateral clearance you want

by turning the wing bolt

(23)

, then retighten the wing

bolt

(22)

.

Height:

 Set the vertical alignment of the pilot according to

the router bit you are using and the thickness of the work-
piece you want to machine.
Loosen the nut

(4)

 on the pilot, slide the pilot into the de-

sired position and retighten the bolt.

Maintenance and servicing

Maintenance and cleaning

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by Bosch or by a
customer service centre that is authorised to repair Bosch
power tools.

After-sales service and advice on using products

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on

spare parts at:

www.bosch-pt.com

The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At

www.bosch-pt.co.uk

 you can order spare parts or ar-

range the collection of a product in need of servicing or re-
pair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com

Ireland

Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888

Australia, New Zealand and Pacific Islands

Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch-pt.com.au
www.bosch-pt.co.nz

Republic of South Africa
Customer service

Hotline: (011) 6519600

Gauteng – BSC Service Centre

35 Roper Street, New Centre
Johannesburg
Tel.: (011) 4939375
Fax: (011) 4930126
E-Mail: bsctools@icon.co.za

KZN – BSC Service Centre

Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: (031) 7012120
