11

12

[1] Typical range: tested while riding with a full battery, 61 lbs (30 kg) load, 77°F (25°C), 60% of max. speed on

average on pavement.
* For the first ride, the default speed mode is the first-gear mode. When the kickscooter powers off, the speed
mode setting will be kept till the next time you turn it on.

WARNING

●

 Do not dispose of this product in a landfill, by incineration, or by mixing with household trash.

Serious danger/injury can occur because of the electrical components.

●

 Before cleaning, Please check to make sure the kickscooter is powered off, the power cord is

unplugged, and the rubber cap on the charging port is tightly sealed; otherwise you may damage
the electrical components.

Wheel

bearing

6. Specifications

7. Maintenance

Maintenance should be carried out by an adult regularly.

Cleaning

Use a soft and wet cloth to clean. Stains hard to remove can be scrubbed with a toothbrush and
toothpaste, then wiped off with a soft and wet cloth.
To prevent jamming to the wheels, wheel bearings, or brakes, please clean and check these areas (as
shown in the gray highlighted areas below) for dirt and other foreign objects.

First clean up the foreign objects, and then wipe clean with a soft wet cloth. Lubricate both sides of
the bearing with lubricating oil or machine oil. If the problem still exists, please contact customer
service.

CAUTION:

To avoid the accumulation of foreign objects, DO NOT ride on muddy, dusty,

grassy or slippery roads. Do NOT clean your kickscooter with alcohol, gasoline, acetone, or other
corrosive/volatile solvents. These substances may damage the appearance and internal structure of
your kickscooter. Do NOT wash your kickscooter with a power washer or hose.

1

2

Item

Ninebot eKickScooter ZING A6

Net Weight
Length × Width × Height
Max. Payload
Recommended Age
Recommended Height

Battery Type
Nominal Voltage
Maximum Voltage
Charging Temperature

Nominal Capacity / Energy
Battery Management System

Nominal Power
Max. Power

Speed Mode (Max Speed)

Typical range

[1]

Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Charging Time

Approx. 10.1 lbs (4.6 kg)
Approx. 25.6 × 12.6 × 33.5 inch (650 × 320 × 850 mm)
88 lbs (40 kg)
6+ yrs.
3’5”–4’7” (105–140 cm)

Lithium-ion battery
10.8 V
12.6 V
32–113°F (0–45°C); 50–95°F (10–35°C) recommended
2500 mAh/27 Wh
Over-heating, short circuit, over-current and over-charge protection
50 W
80 W (0.08 kW)

Input Voltage
Rated Output
Output Power

100–240V~
11.6 V         , 1.0 A
11.6 W (0.01 kW)

Braking Method
Tires
Frame Material

Overcurrent protection value

Handlebar Material

Rear-fender brake
Front wheel: PU perfusion, Rear wheel: Rubber solid
Steel
7.5 A
TPR

First-gear speed: 5.0 mph (8 km/h), second-gear speed: 6.2 mph
(10 km/h), third-gear speed: 7.5 mph (12 km/h)
Approx. 3.1 miles (5 km)

Flat surface, paved road; obstacles < 0.4 in (1 cm); gaps < 0.4 in (1 cm)

14–104°F (-10–40°C)
-4–122°F (-20–50°C); 41–86°F (5–30°C) recommended
IPX4
Approx. 3 h

Weight and
Size

Rider
Requirement

Vehicle
Parameters

Battery
Pack

Motor

Battery
Charger

Others
