12

 | English

1 609 92A 43S | (21.8.17)

Bosch Power Tools

Intended Use

The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Key type drill chuck

2

“Drilling/Impact Drilling” selector switch

3

Lock-on button for On/Off switch

4

On/Off switch

5

Rotational direction switch

6

Wing bolt for depth stop adjustment

7

Wing bolt for adjustment of auxiliary handle

8

Auxiliary handle (insulated gripping surface)

9

Depth stop

10

Handle (insulated gripping surface)

11

Chuck key

12

Screwdriver bit *

13

Universal bit holder *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1, EN 60745-2-2.

Typically the A-weighted noise levels of the product are:
Sound pressure level 95 dB(A); Sound power level
106 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-1:
Drilling into metal: a

h

= 7.5 m/s

2

, K = 1.5 m/s

2

Impact drilling into concrete: a

h

= 10.5 m/s

2

, K = 1.5 m/s

2

Screwdriving without impact: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

Tapping: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Assembly



Before any work on the machine itself, pull the mains
plug.

Auxiliary Handle (see figure A)



Operate your machine only with the auxiliary handle 8.

The auxiliary handle

8

 can be set to any position for a secure

and low-fatigue working posture.

Turn the wing bolt for adjustment of the auxiliary handle

7

 in

anticlockwise direction and set the auxiliary handle

8

 to the

required position. Then tighten the wing bolt

7

 again in clock-

wise direction.

Adjusting the Drilling Depth

The required drilling depth

X

 can be set with the depth stop

9

.

Loosen the wing bolt for the depth stop adjustment

6

 and in-

sert the depth stop rod into the auxiliary handle

8

.

The knurled surface of the depth stop

9

 must face upward.

Pull out the depth stop until the distance between the tip of
the drill bit and the tip of the depth stop corresponds with the
desired drilling depth

X

.

Retighten the wing bolt for the depth stop adjustment

6

 again.

Changing the Tool



Wear protective gloves when changing the tool.

The

drill chuck can become very hot during longer work peri-
ods.

Key Type Drill Chuck (see figure B)

Open the key type drill chuck

1

 by turning until the tool can be

inserted. Insert the tool.

Impact Drill

GSB 1300

Article number

3 601 AA1 0..

Rated power input

W

550

Output power

W

270

No-load speed

min

-1

0 – 2 800

Impact frequency at no-load

min

-1

0 – 41 800

Rated torque

Nm

1.5

Right/left rotation



Spindle collar dia.

mm

43

Max. drilling dia.
– Brickwork
– Concrete
– Steel
– Wood

mm
mm
mm
mm

13
13
10
25

Chuck clamping range

mm

1.5 – 13

Weight according to EPTA-
Procedure 01:2014

kg

1.8

Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
