05

Frequency

5-55-10 Hz

Duration

30 minutes

Amplitude

0.35 mm

6.2 Altitude

The power supply can operate normally at any altitude between 0 to 10000 feet.

6.3 Vibration and Shock

Sweep and resonance search for each of X,Y,Z, axis at the sweep.
RATE of 1/OCTAVE/Min.

CE,FCC

7. Conducted EMI

cTUVus, CB,TUV

8.1 Safety Requirement

The AC leakage current is less than 3.5mA when the power supply connect to 264Vac/50Hz .

8.2 Leakage Current

The insulation resistance should be not less than 30M ohm after applying of 500VDC for 1 minute.

8.3 Insulation Resistance

The power supply shall withstand for 1 minute without breakdown the application of  a 60Hz 1500V AC
voltage applied between both input line and chassis (20mA DC cut-off current). Main transformer shall
similarly withstand 3000Vac applied between both primary and secondary windings for a minimum of one
minute.

8.4 Dielectric Voltage Withstand

8. Product Safety

A TTL compatible signal for the purpose of initiating an orderly start-up procedure under
normal input operating conditions. During power up, this signal is asserted ( low ) until
+5V is under regulation and AC reaches min. line specification range. After all voltage
are going appropriate level, the system may have a turn on delay of 100mS, but no
greater than 500mS. During power off the signal should go to low level before +5V
is out of regulation. The low level is 0 to 0.8V and high level is 4.75 to 5.25V. The
" Power Good "signal can drive up to 6 standard TTL loads.

9. Power Good Signal

6.1.2 Storage

Temperature

-40 to 70C

Relative Humidity

20 to 95 % noncondensing
