RELIABLE PERFORMANCE FOR PC BUILDS

Trouble shooting

WARNING:

Never work on the PSU yourself. Even long time after its deactivation,
life-threatening voltages can still be present in the PSU. Repairs should only be
made by authorized specialists.

Working at power sources can lead to life-threatening injuries. If there is smoke,
cable damage or intrusion of liquids the PSU has to be immediately disconnected
from the power network and must not to be put into operation anymore afterwards.
Never open the PSU. It contains components, which can show high voltages even
after long periods of deactivation.
Again, repairs should only be done by authorized specialists!

Problem: After the installation of the new PSU the system does not start.
Possible solutions:

●

Check the power code and the power supply of the wall socket and/or multiple

   socket strip. Also check whether the multiple socket strip can supply the
   necessary power.

●

Check all connections within the PC; maybe not all cables are correctly connected.

●

Check the internal cable of the I/O-switch of the PC case to the mainboard.

●

Check the components for possible short-circuits or defects.

Please also check the other components for compatibility. Often mainboard chipsets
are not compatible with all memory and/or graphics card solutions. Contact the
manufacturer of the component to get more information.

If your PSU still does not function even though you have checked sources of errors
mentioned above, please get in touch with our customer service.

Advice

This product is not to be disposed in the regular household waste and
must be brought to a collection-point for electrical and electronic devices
for recycling. The symbol to the left refers to that and can be found on the
product, in the manual or on the packaging. Materials can be recycled
according to their description. With the reuse, the recycling or other forms
of reutilization of old devices you make an important contribution to the
protection of our environment. Please inquire the appropriate location of
disposal from your local administration.

Introduction

Dear customer:
Thank you for choosing a COUGAR

®

 power supply unit. Before the installation

please read the manual below carefully. If you have any questions, please contact
our customer service:

Warnings and safety notes

Never open the PSU cover. There is potential danger of life due to high voltage inside.
The PSU should only be opened by an authorized technician. The manufacture
warranty will be void, if the PSU is opened by an unauthorized person.

Do not work on the PSU or the PC as long as the main voltage is still connected.
Switch the I/O button to position "0" and disconnect the power plug from the power
network.

Protect the PSU against moisture.

The PSU is suitable for operation at 100-240V/50-60Hz.
The ambient temperature should not exceed 50°. Please pay attention to the power
de-rating on all models with a decrease of 1%/°C starting at an ambient temperature
of 25°C. Please ensure that there is sufficient ventilation of the entire system.

The leakage current must not exceed 3.5 mA.

Make sure during the installation of the PSU that the ventilation slots are not covered.
Do not clog the ventilation slots of the PSU. Keep your PC away from direct heat
sources such as radiators.

When using an extension cord and/or multiple sockets pay attention to the maximum
through-connection ability in order to avoid short-circuits.

If you want to clean your PSU, disconnect the power plug from the power network
and remove it from the PC case. Before the removal make sure that you are not
statically charged, (e.g. through carpets or wool sweaters).Only clean the PSU on the
outside, always using dry cloth, never water or detergent.

During the operation of the PSU pay attention to the maximum loads. The single
loads and the total loads must not exceed to cross the values shown in output power
table. Avoid the use of adapters, such as 4Pin Molex to 6+2Pin PCI-Express.

Specifications

●

Operating conditions

   Working temperature:
   +10°C ~ +40°C (Please note the de-rating condition in Warnings and safety notes)
   Storage temperature:
   -40°C~+70°C
   Operating humidity (without condensation water):
   20%~85% relative humidity
   Storage humidity (without condensation water):
   5%~95% relative humidity

●

Connectors

●

Output power

Main

CPU

24(20+4)

Pin

8(4+4)

Pin

Peripheral

S-ATA

PCI-E

Pin

Connector

5 Pin

8(6+2)

Pin

4 Pin

1

2

4

1

1

V T E 4 0 0

1

2

5

2

1

V T E 5 0 0

1

2

6

2

1

V T E 6 0 0

+3.3V

16A

120W

360W

0.3A

2.5A

400W

18A

30A

+5V

+12V

Total

-12V

+5Vsb

AC input

Model Name

DC output

V T E 4 0 0

C G R   B S - 4 0 0

135W

450W

0.3A

2.5A

500W

16A

18A

37.5A

V T E 5 0 0

C G R   B S - 5 0 0

150W

540W

0.3A

2.5A

600W

16A

20A

45A

V T E 6 0 0

C G R   B S - 6 0 0

100-240V~

50-60Hz

10-6A

100-240V~

50-60Hz

6.5-4A
