5.1 Active Home Theater

Speaker System

ENG

24

Remote control

a

 POWER: POWER button

b

 RESET: return to default settings

c

 MUTE: sound off/on button

d

 INPUT: audio input selection button

e

 2.1/5.1: 2.1/5.1 mode selection button

f

 TREBLE+/-: treble level control buttons

g

 BASS+/-: bass level control buttons

h

 FRONT +/-: front channel volume control buttons

i

 CENTRE +/-: center channel volume control buttons

j

 REAR+/-: surround speakers channel volume control buttons

k

 SUB+/-: subwoofer channel volume control buttons

l

 VOLUME +/-: master volume control buttons

Remote control battery installation

•

 Open the battery compartment on the back of the remote control.

•

 Insert 2 AAA type batteries (included).

•

 Close the battery compartment.

Notes:

•  Use  the  remote  control  at  an  angle  of  no  more  than  30°,  no

more than 7 meters away.

• Direct the RC at the IR receiver display on the subwoofer.

•  If  the  remote  control  does  not  work,  check  the  battery  or  re

-

place the discharged battery with a new one.

• Remove the battery from the remote control if you don’t intend

to use it for a long time (more than a week).

5. PREPARATION AND OPERATION

Speaker placement

•

To achieve optimum sound, it’s recommended that you place the

speakers according to Fig. 5. The center and front speakers should

be located along an imaginary circle with the distance between the

listener  and  the  center  channel  speaker  as  a  radius,  and  the  lis-

tener’s  head  as  the  center.  Each  of  the  three  speakers  should  be

placed  at  equal  distance  from  the  listener.  The  front  speakers  and

the  listener  make  up  an  equilateral  triangle.  The  rear  speakers  are

placed  at  the  same  distance  from  the  listener  (on  the  imaginary

circle, too) at an angle of nearly 110° to the Listener – Display axis.

•

Avoid placing your speakers in the corners and close to walls, as

this  can  lead  to  unwanted  resonance  and  distortions.  If  possible,

place them at least 20 cm away from walls.

•

For more accurate perception, the tweeters should be at the listener’s ear level.

•

Do not locate the speakers in niches. Such placement can affect the sound badly, especially in the lows.

•

The subwoofer emits non-directional sound, therefore it can be located in any place of the room where

it sounds the best.

Fig. 3. Remote control

Fig. 4. Battery installation
