Wi-Fi

Wi-Fi

TP-Link_Extender

CHOOSE A NETWORK...

Other...

< Settings

My Devices

Local Device

RExxx

XX-XX-XX-XX-XX-XX

Q1. What should I do if the Tether app cannot find my device during

setup?

Try another method by following the steps below:
1.  Connect your smartphone to the extender’s network

TP-Link_Extender

.

2. Launch the Tether app, and select your extender.

3. Follow app instructions to complete the setup.

If you are still having problems, contact our technical support.

Q2. What should I do if the        LED doesn’t turn solid on after

completing setup via the Tether app or web browser?

You may have entered incorrect Wi-Fi password for your host router during the

configuration. Check the password and try again.

Make sure the extender is close to your router, preferably within 16 feet, and away

from large electrical appliances.

If you have enabled wireless MAC filtering, wireless access control, or access

control list (ACL) on your router, disable them first, then follow any method on the

front page to complete the configuration.

Try setting it up via the WPS button.

Reset the extender and go through the configuration again.

If you are still having problems, contact our technical support.

Q3. How do I reset the extender?

With the extender powered on, use a pin to press the

RESET

 button for 1 second.

The extender will reboot.

Safety Information

Keep the device away from water, fire, humidity or hot environments.

Do not attempt to disassemble, repair, or modify the device. If you need service, please

contact us.
Do not use the device where wireless devices are not allowed.
The socket-outlet shall be installed near the equipment and shall be easily accessible.

Please read and follow the above safety information when operating the device. We cannot

guarantee that no accidents or damage will occur due to improper use of the device.

Please use this product with care and operate at your own risk.
TP-Link hereby declares that the device is in compliance with the essential requirements

and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and

(EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce.

For technical support, the user guide and other information, please

visit

https://www.tp-link.com/support/

, or simply scan the QR code.

If you have any suggestions or needs for our product guides, you

are welcome to email

techwriter@tp-link.com.cn

.

To communicate with TP-Link users or engineers, please join the

TP-Link Community at

https://community.tp-link.com

.

Tip:

If you have connected to the extender’s Wi-Fi but still cannot find your device, try turning off

your cellular data.

Method 2: Via a Web Browser

Method 1: Via the Tether App

1.

Connect your computer or smartphone to the extender’s network

.

 If you are

using a computer, unplug the Ethernet cable if any.

2.

Launch a web browser, enter

 http://tplinkrepeater.net

 in the address bar, and

log in.

3.

Manage the extender as needed.

1.

Connect your smartphone to the extender‘s or router’s network.

2.

Launch the Tether app, select your extender, and log in.

3.

Manage the extender as needed.

Manage the Extender

After setup, you can manage the extender via any of the methods below.

Note:

If your extender and router use the same network name, Method 1 is recommended.

TP-Link OneMesh

TM

 router and extenders work together to form one unified

Wi-Fi network. Walk through your home and stay connected with the fastest

possible speeds thanks to OneMesh’s seamless coverage.

OneMesh

TM

 with Seamless Roaming

Seamless Roaming

Devices automatically switch between your router and extenders as you move through your

home for the fastest possible speeds.

Unified Wi-Fi Network

Router and extenders share the same wireless settings, including network name, password,

access control settings and more.

Easy Setup and Management

Set up a OneMesh network with a push of WPS buttons. Manage all network devices on the

Tether app or at your router’s web management page.

To check full list of TP-Link OneMesh devices, scan the QR code,

or visit

https://www.tp-link.com/One-Mesh/compatibility

.

LED Explanation

The extender is connected or not connected to the

5GHz wireless network of your host router.

5GHz

Status

Indication

On/Off

The extender is connected or not connected to the

2.4GHz wireless network of your host router.

2.4GHz

On/Off

The extender is on or off.
The system is starting up or firmware is being

upgraded.

(Power)

On/Off

Blinking

WPS connection is established.
WPS connection is in progress.
WPS connection has been established for more

than 5 minutes or WPS connection failed.

(WPS)

On

Blinking

Off

The extender is connected to your router’s wireless

network and is in a suitable location.
The extender is experiencing poor signal strength.

Try relocating it closer to your router.
No wireless connection is established.

(Signal)

Solid blue

Solid red

Off

5GHz

2.4GHz

Signal

Power

WPS

RESET
