1.-

2.-

Instructions for use

By pushing buttons shown in the figure 1, you
will be able to control the functions of the
extractor

Two achieve better extraction, we recommend
switching on the extractor a few minutes
before starting to cook (3 - 5 minutes) so that
the air flow is continuous and stable when
extracting the fumes.

Likewise, keep the extractor switched on for a
few minutes when cooking is complete to
allow all fumes and odours to be expelled.

Cleaning and maintenance

Before carrying out any cleaning or
maintenance activities, ensure that the
extractor is disconnected from the mains.
To carry out cleaning and maintenance, follow
the Safety Instructions.
There is a fire risk if cleaning is not carried out
in accordance with the instructions.

Filter cleaning

To remove the filters from their locations
release the anchoring points. Clean the filter,
either by putting it in the dishwasher (see
notes) or leaving it standing in hot water to
simplify the removal of grease or, if wished, by
means of special sprays (protecting the non
metallic parts). Once clean, leave it to dry.

Notes:

 cleaning in the dishwasher with

aggressive detergents may darken the surface
of metallic parts, without this affecting its gas
retaining properties.

N.B.

The filter must be cleaned at least once a

month depending on how often the extractor is
used. It must be remembered that grease
accumulates in the extractor when cooking,
whether it is switched on or not.

Cleaning of the extractor body

The use of warm (40ºC approx.) soapy water
is recommended. A cloth moistened in this
water is used for cleaning the extractor, paying
special attention to the grids. Afterwards, dry it
using a lint-free cloth.


Note:
*

Never use metallic scouring pads or abrasive
products that could damage the surface.

* Do not use scrapers with metallic surfaces

such as knives, scissors etc.

Active charcoal filter

*  To install the charcoal filter press the anchor

points onto each side of the motor and turn
clockwise.

* The carbon filters last from three to six

months depending on the particular
conditions of use.

* The activated carbon filters can neither be

washed nor regenerated. Once they are
exhausted, they must be changed.

* To replace used filters with new ones,

withdraw the old ones in the reverse order to
that of installation

.

Changing Bulbs

*

It is important that the mains are
disconnected, and ensure the bulbs that are
to be replaced are not hot.

* Remove the light lens to expose the

extractable lamps.

*  The maximum bulbs power is 20W.


Technical Information

(Fig.3)


Dimensions

Width = 550 mm
Depth = 310 mm
Height = 190 mm

Dimensions for fitting


Width = 505 mm
Depth = 292 mm

Electrical characteristics:
REFER TO RATING PLATE


Speed Vitesse Velocidad Velocità Snelheid Absaugleistung

Скорость

Velocidade Hastighet

First Première

Primera Prima Eerste

Erste

Первая

 Primeira  Första

Second Deuxième Segunda Seconda Tweede

Zweite

Вторая

 Segunda  Andra

Third Troisième

Tercera Terza  Derde

Dritte

Третья

 Terceira  Tredje

Stop Arrêt

Parada

Arresto

Afweren

Halt

Стоп

 Parar Parade

Light Lumière Luz Luce

Licht

Beleuchtung

Свет

 Luz Lampa

On Allumé

Encendido Accesa

Aan

Ein

Включен

Acesa På

Off Eteint

Apagado

Spenta

Uit

Aus

Выключен

Desligada Av

G

H

B

A

C

D

E

F
