22

ENGLISH

Cooker hood

TECHNICAL PASSPORT

is damaged, request a new one from

Technical Service.

MOUNTING

Very heavy product; hood handling

and installation must be carried out by

at least two persons.

Before beginning installation:

•  Check  that  the  product  purchased

is of a suitable size for the chosen in-

stallation area.

•  Remove  the  charcoal  (*)  filter/s  if

supplied (see also relative paragraph).

This/these is/are to be mounted only if

you want lo use the hood in the filtering

version.

•  Check  (for  transport  reasons)  that

there is no other supplied material in-

side the hood (e.g. packets with screws

(*), guarantees (*), etc.), eventually re-

moving them and keeping them.

•  If  possible,  disconnect  and  move

freestanding or slide-in range from cab-

inet opening to provide easier access to

rear wall/ceiling. Otherwise put a thick,

protective covering over countertop,

cooktop or range to protect from dam-

age and debris. Select a flat surface for

assembling the unit. Cover that surface

with a protective covering and place all

canopy hood parts and hardware in it.

•  In  addition  check  whether  near  the

installation area of the hood (in the area

accessible also with the hood mounted)

an electric socket is available and it is

possible to connect a fumes discharge de-

vice to the outside (only suction version).

•  Carry  out  all  the  masonry  work

necessary (e.g. installation of an electric
socket and/or a hole for the passage of
the discharge tube).

Expansion wall plugs are provided to

secure the hood to most types of walls/

ceilings. However, a qualified technician

must verify suitability of the materials in

accordance with the type of wall/ceiling.

The wall/ceiling must be strong enough

to take the weight of the hood. Do not

tile, grout or silicone this appliance to

the wall. Surface mounting only.

Using

The hood can be operated by using

the control panel (see drawing)

The control panel consists of:

-   “0/1” – motor on/off;

-  “2” – second speed of the motor,

-  “3” – third speed of the motor,

-  “L” – light on/off.

MAINTENANCE

Â

Attention!

 Before performing

any maintenance operation, isolate

the hood from the electrical supply by

switching off at the connector and re-

moving the connector fuse.

Or if the appliance has been con-

nected through a plug and socket, then

the plug must be removed from the

socket.

CLEANING

The cooker hood should be cleaned

regularly (at least with the same fre-

quency with which you carry out main-

tenance of the fat filters) internally and

externally. Clean using the cloth damp-
