Integrated extractor hood SLIMLUX II

potential harm to human health and the
environment. The symbol of a rubbish
container superimposed by a diagonal
cross should be put on all such products
to remind people of their obligation to
have such items collected separately.

Consumers should contact their local

authorities and request information on
the appropriate places to leave their old
home electrical appliances.

Before disposing of your appliance,

render it non-usable by pulling out the
power cable, cutting this and disposing
of it.

4.  B R I E F  D E S C R I P T I O N

This device is designed for purifying

the air from smoke, combustion gases,
vapors, odors and other undesirable
impurities which are formed during the
cooking process and accumulate in the
kitchen.

5.  M A I N T E N A N C E  A N D

I N S TA L L AT I O N  M A N U A L

5.1. Safety Installation

The lower part of the extractor

must be located at a minimum height
of 60 cm above the hob for electric
cookers and 70 cm for gas cookers. If
the instructions of a gas cooker indicate
a greater distance these must be
observed.

5.2. Installing the appliance

To  fi x  the  extractor  to  the  kitchen

unit the pattern on fi g. 4 is used.

To achieve optimum performance

the length of the outlet hose should not
exceed 4 meters, or include more than
two 90º angles (elbows).

Although venting to the outside is

recommended,  activated  carbon  fi lters
may be used, which allow the gas to
be returned to the kitchen through the
outlet pipe.

If you wish to exchange the front for

one matching the kitchen units, follow
the following instructions (Fig. 3):



Withdraw the movable group.



Remove the screws (T) that

support the front.



Install  the  new  front  fi xing  it

with the same screws that held the old
one.

5.3. Electrical connection

We recommend that the appliance

is  connected  by  a  qualifi ed  electrician,
who will comply with local regulations.

Should the colour of the wires in

the mains lead for the appliance not
correspond with the coloured markings
identifying the terminal in your spur
box proceed as follows:



The wire which is coloured blur

must be connected to the marked N
(Neutral) or coloured Black.



The wire which is coloured

brown must be connected to the marked
L (Live) or couloured Red
