8
ENGLISH
Cooker hood
TECHNICAL PASSPORT
13W LED-STRIP
USE
The hood is designed to be used
either for exhausting or filter version.
DUCTING VERSION
In this case the fumes are conveyed
outside of the building by means of
a special pipe connected with the
connection ring located on top of the
hood.
Attention! The exhausting pipe is
not supplied and must be purchased
apart.
Diameter of the exhausting pipe
must be equal to that of the connection
ring.
In the horizontal runs the exhausting
pipe must be slightly slanted (about
10°) and directed upwards to vent the
air easily from the room to the outside.
Attention! If the hood is supplied
with active charcoal filter, then it must
be removed.
Connect the hood and discharge
holes on the walls with a diameter
equivalent to the air outlet (connection
flange).
Using the tubes and discharge
holes on walls with smaller dimensions
will cause a diminution of the suction
performance and a drastic increase in
noise.
Any responsibility in the matter is
therefore declined.
!
Use a duct of the minimum
indispensible length.
!
Use a duct with as few elbows as
possible (maximum elbow angle:
90°).
!
Avoid drastic changes in the duct
cross-section.
!
Use a duct as smooth as possible
inside.
!
T he duct must be made of certified
material.
FILTER VERSION
One active charcoal filter is needed
for this and can be obtained from your
usual retailer.
The filter removes the grease and
smells from the extracted air before
sending it back into the room through
the upper outlet grid.
