ENGLISH

TECHNICAL PASSPORT

Cooker hood

with a plug (direct mains connection)

or if the plug is not located in an ac-

cessible area, after installation, apply a

double pole switch in accordance with

standards which assures the complete

disconnection of the mains under con-

ditions relating to overcurrent category

III, in accordance with installation in-

structions.

WA R N I N G!

 Before re-connecting

the hood circuit to the mains supply and

checking  the  efficient  function,  always

check that the mains cable is correctly

assembled. The hood is provided with a

special power cable; if the cable is dam

-

aged, request a new one from Technical

Service.

MOUNTING

Very  heavy  product;  hood  handling

and installation must be carried out by

at least two persons.

Before beginning installation:

Â

Check that the product purchased

is of a suitable size for the chosen

installation area.

Â

Remove the charcoal (*) filter/s if

supplied (see also relative paragraph).

This/these is/are to be mounted only if

you want lo use the hood in the filtering

version.

Â

Check (for transport reasons)

that there is no other supplied material

inside the hood (e.g. packets with

screws (*), guarantees (*), etc.), eventually

removing them and keeping them.

Â

If possible, disconnect and move

freestanding or slide-in range from

cabinet opening to provide easier

access to rear wall/ceiling. Otherwise

put a thick, protective covering over

countertop, cooktop or range to protect

from  damage  and  debris.  Select  a  flat

surface for assembling the unit. Cover

that surface with a protective covering

and place all canopy hood parts and

hardware in it.

Â

In addition check whether near

the installation area of the hood (in

the area accessible also with the hood

mounted) an electric socket is available

and it is possible to connect a fumes

discharge device to the outside (only

suction version).

Â

Carry out all the masonry work

necessary (e.g. installation of an electric

socket and/or a hole for the passage of

the discharge tube).

Expansion wall plugs are provided

to secure the hood to most types of

walls/  ceilings.  However,  a  qualified

technician must verify suitability of the

materials in accordance with the type of

wall/ceiling. The wall/ceiling must be

strong enough to take the weight of the

hood. Do not tile, grout or silicone this

appliance to the wall. Surface mounting

only.

*contingent on the model
