sure that this appliance is disposed of in a suitable manner, the

user is helping to prevent potential damage to the environ-

ment or to public health.

The symbol on the product or on the accompanying

paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to

a suitable electric and electronic appliance recycling collection

point. Follow local guidelines when disposing of waste. For

more information on the treatment, re-use and recycling of

this product, please contact your local authority, domestic

waste collection service or the shop where the appliance was

purchased.

 INSTALLATION INSTRUCTIONS

•  Assembly and electrical connections must be carried out

by specialised personnel.

•  Wear  protective  gloves  before  proceeding  with  the

installation.

•  Electric Connection:

- The appliance has been manufactured as a class II, therefore

no earth cable is necessary. The plug must be easily acces-

sible after the installation of the appliance. If the appliance

is equipped with power cord without plug, a suitably di-

mensioned omnipolar switch with 3 mm minimum opening

between contacts must be fitted between the appliance and

the electricity supply in compliance with the load and current

regulations.

- The connection to the mains is carried out as follows:

BROWN =

L

 line

BLUE =

N

 neutral.

•

If the hob is electric, gas, or induction, the minimum distance

between the same and the lower part of the hood must be

at least

65 cm

. If a connection tube composed of two parts is

used, the upper part must be placed outside the lower part.

Do not connect the cooker hood exhaust to the same con-

ductor used to circulate hot air or for evacuating fumes from

other appliances generated by other than an electrical source.

Before proceeding with the assembly operations, remove the

anti-grease filter(s) (Fig.4) so that the unit is easier to handle.

-  In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

•

We recommend the use of an air exhaust tube which has the

same diameter as the air exhaust outlet hole. If a pipe with

a smaller diameter is used, the efficiency of the product may

be reduced and its operation may become noisier.

•

If your appliance has been designed for use in habitations

supplied with acentralised suction device perform the follow-

ing operations:

- The switch controls opening and closure of a valve using

a thermoelectical device. By placing the switch in the

ON

position, after a minute, the valve opens rotating 90° allow-

ing suction of the stale air. By placing the switch in the

 OFF

position, the valve closes after 100 seconds.

•  Installation:

The following instruction should be followed to carry out the

correct installation of the cooker hood:

1. Mounting of the cooker hood on the lower side of the

cupboard.

2. Selection of the version (extraction Fig.3A or filtration

Fig.3B).

•  Optional!

As an alternative installation, require to your dealer a KIT of

pensile side fittings (Fig.2A).

•

Fixing the hood to the lower part of the wall cabinet:

This type of appliance must be fitted inside a cabinet or inside

another type of support structure. To fix it in place, use 4 screws

which are suitable for the type of cabinet, making holes in ac-

cordance with the diagram shown in Fig.1. To fit the appliance

correctly, align the front panel of the cooker hood with the

cabinet door and adjust spacer

L

 using screws

P

 (Fig.2), then

ensure the appliance meets the cabinet at the rear.

•  Extraction through an outside wall:

The appliance expels the fumes through an outside wall or

a duct. It is necessary to buy a telescopic pipe in accordance

with the standards in use (inflammable) and connect it to

flange

H

 (Fig.3A).

•  Recirculation:

To transform the cooker hood from the extraction version to

the re circulating one ask your supplier for an activated carbon

filter. The filter must be fitted to the extracting group cooker

hood in the centre of the fan grille by twisting it by 90 degrees

until it is gripped securely (Fig.5). For this operation remove the

anti-grease filter(s)

G

 (Fig.4). The clean air is returned into the

room through a connecting tube passing inside the cupboard

and connected to the ring

H

 (Fig.3B).

 USE AND MAINTENANCE

•

We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air. The effective

performance of the cooker hood depends on constant main-

tenance; the anti-grease filter and the active carbon filter both

require special attention.

•  The  anti-grease  filter

 is responsible retaining the grease

particles suspended in the air, therefore it is subject to clog-

ging with variable frequency according to the use of the

appliance.

-  To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease filters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

-  After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•  The active carbon filters

 are used to purify the air that is

sent back into the room and its function is to mitigate the

unpleasant odours produced by cooking.

-  The non-regenerable active carbon filters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease filter is cleaned.

•  Before remounting the anti-grease filters and the regen

-

erable active charcoal filters it is important that they are

completely dry.

•  Clean  the  hood  frequently,  both  internally  and  exter

-

nally, using a cloth dampened with denatured alcohol or

neutral liquid detergents that are non abrasive.

•

The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system significantly decreases

the average duration of the bulbs.

•

If the appliance is equipped with courtesy lights it is possible

- 5 -
