•  Fixing the decorative telescopic flue:

Arrange the electrical power supply within the dimensions of

the decorative flue. If your appliance is to be installed in the

ducting version or in the version with external motor, prepare

the air exhaust opening. Adjust the width of the support

bracket of the upper flue (Fig.3). Then fix it to the ceiling using

the screws

A

 (Fig.3) in such a way that it is in line with your

hood and respecting the distance from the ceiling indicated

in Fig.2. Connect the flange

C

 to the air exhaust hole using a

connection pipe (Fig.4). Insert the upper flue into the lower

flue. Fix the lower flue to the hood using the screws

B

 provided

(Fig.4), extract the upper flue up to the bracket and fix it with

the screws

B

 (Fig.3). To transform the hood from a ducting

version into a filtering version, ask your dealer for the charcoal

filters and follow the installation instructions.

•  Filtering version:

Install the hood and the two flues as described in the

paragraph for installation of the hood in ducting version. To

assemble the filtering flue refer to the instructions contained

in the kit. If the kit is not provided, order it from your dealer

as accessory. The filters must be applied to the suction unit

positioned inside the hood. They must be centred by turning

them 90 degrees until the stop catch is tripped (Fig.7).

  USE AND MAINTENANCE

•

We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air.

The effective performance of the cooker hood depends on

constant maintenance; the anti-grease filter and the active

carbon filter both require special attention.

•  The  anti-grease  filter

 is responsible retaining the grease

particles suspended in the air, therefore it is subject to

clogging with variable frequency according to the use of the

appliance.

-  To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease filters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

-  After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•  The active carbon filters

 are used to purify the air that is

sent back into the room and its function s to mitigate the

unpleasant odours produced by cooking.

-  The non-regenerable active carbon filters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease filter is cleaned.

-  Regenerable active charcoal filters must be washed by hand,

with non abrasive neutral detergents, or in the dishwasher at

a maximum temperature of 65°C (the washing cycle must be

complete without dishware). Remove excess water without

damaging the filter, remove the plastic parts, and let the mat

dry in the oven for at least 15 minutes approximately at a

maximum temperature of 100°C. To keep the regenerable

charcoal filter functioning efficient this operation must be

repeated every 2 months. These must be replaced at least

every 3 years or when the mat is damaged.

•  Before remounting the anti-grease filters and the regen

-

erable active charcoal filters it is important that they are

completely dry.

•  Clean  the  hood  frequently,  both  internally  and  exter

-

nally, using a cloth dampened with denatured alcohol or

neutral liquid detergents that are non abrasive.

•

The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system significantly decreases

the average duration of the bulbs.

•

If the appliance is equipped with courtesy lights it is possible

to use them for general room lighting for a prolonged amount

of time.

•  Attention:

 the non compliance with the hood cleaning

warnings and with the replacement and cleaning of the filters

entails risk of fires. One therefore recommends keeping to the

suggested instructions.

•  Replacing halogen light bulbs (Fig.8A):

To replace the halogen light bulbs

B

, remove the glass pane

C

 using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution:

 do not touch the light bulb with bare hands.

•  Replacing the halogen/incandescent lamps (Fig.8B):

Only use lamps of the same type and wattage installed on

 the device.

•  Commands  (Fig.9)  mechanical

 the key symbols are ex-

plained below:

A

=

 LIGHT

B

=

 OFF

C

=

 SPEED I

D =

 SPEED II

E

=

 SPEED III.

•  Commands  (Fig.10)  luminous

the key symbols are ex-

plained below:

A =

 LIGHT

B

=

 OFF

C

=

 SPEED I

D =

 SPEED II

E

=

 SPEED III

F   =

 AUTOMATIC STOP TIMER - 15 minutes

(*)

If your appliance does not have the

INTENSIVE

 speed

function, press key

E

 for two seconds and it will be activated

for 10 minutes after which it will return to the previously set

speed. When the function is active the LED flashes. To interrupt

it before the 10 minutes have expired press key

E

again.

By pressing key

F

for two seconds (with the hood switched

off )  the “

clean air

” function is activated. This function switches

the appliance on for ten minutes every hour at the first speed.

As soon as this function is activated the motor starts up at the

first speed for ten minutes. During this time key

F

and key

C

must flash at the same time. After ten minutes the motor

switches off and the LED of key

F

remains switched on with

a fixed light until the motor starts up again at the first speed

after fifty minutes and keys

F

and

C

start to flash again for ten

minutes and so on. By pressing any key for the exclusion of

the hood light the hood will return immediately to its normal

functioning (e.g. if key

D

 is pressed the “

clean air

” function is

deactivated and the motor moves to the 2nd speed straight

away. By pressing key

B

the function is deactivated).

(*)

 The “

AUTOMATIC STOP TIMER

” delays stopping of the

hood, which will continue functioning for 15 minutes at the

operating speed set at the time this function is activated.

•  Active carbon/grease filter saturation:

- When  button

A

 flashes at a frequency of

2 seconds

, the
