20

Activated carbon filter

5.

Insert the activated carbon filter at the
rear, fold up and lock in the middle with
the wing nut. If the spacer rail has been
removed, it must be re-installed.

6.

Re-insert the two filter cartridges.

Removing the activated carbon filter:

❑

The activated carbon filter is removed in
reverse sequence.

Changing the activated carbon filter:

If used normally (1 to 2 hours daily), the
activated carbon filter should be changed
approx. once a year.

Activated carbon filters can be purchased
from SPECIALIST OUTLETS (see optional
accessories on the last page).

Use original filters only.

This will ensure

optimum performance.

Disposing of the old activated carbon
filter:

Activated carbon filters do not contain any
pollutants. They can be disposed of e.g. as
residual waste.

Extractor hoods with two filter cartridges:

1.

Remove the filter cartridge.

❑

See grease filter.

2.

Insert the screw through the wing nut
and the sleeve and screw in the middle
screw in the false bottom (required only
during the initial installation). Screw,
sleeve and wing nut are enclosed with
the activated carbon filter.

3.

Using a screwdriver, press in the two
lugs on the false bottom. If a spacer rail
has been installed, it must be removed.

4.

Tape over the activated carbon filter with
the enclosed sealing strip.
