17

Pushbutton -

Press to reduce motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and
the timer LEDs).

Pushbutton +

Press to increase motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and
the timer LEDs).

(In the 4-speed version the pushbutton + blinks. The fourth speed remains on for a set
duration of time. After 15 minutes the motor returns to the third speed).

Mode pushbutton

Function: it turns hood motor on and off.

 The

function

“desired speed”

 enables to start the motor at the speed that was selected

before the hood was last turned off.

 Optional:

version with remote control (some versions only).

WARNING:

Install the hood away from sources of electromagnetic waves, as these could affect the
correct operation of the electronic system.

Maximum operating distance: 5 metres. The maximum operating distance could be less
than 5 metres in case of electromagnetic interference by other equipment.

Light pushbutton on remote control:  light on/off.

– and + pushbutton: increase/decrease speed (to start the motor press either the + or the
– pushbutton).

Timer pushbutton: see instructions below.

Timer and ‘filter clogged’ alarm pushbutton

• This function allows the automatic turning off of the hood after running for 15 minutes at
the speed previously set (the pushbutton shows a flickering light).

• After about 30 hours of running the pushbutton indicates the need for washing the metal
filters (the pushbutton shows a solid red light). To disable the alarm press the pushbutton
for a few seconds until the red light turns off. Then turn the hood off and on again to check
that the alarm has disappeared.

FILTERS

REMOVING AND REPLACING’S INSTRUCTIONS

H

1.   METAL FILTERS

Pull on the specific handle to remove the metal filters.

2.   CARBON FILTERS

To replace the active carbon fi lters, proceed as follows: remove the metal fi lter as indi-
cated above Now the motor compartment can be accessed and it is possible to proceed
with assembling/disassembling the carbon fi lters as illustrated in the fi gure below.

To order new carbon fi lters contact your distributor/dealer.
