18

Function of the

remote control

DESCRIPTION

‘ + ‘ Key

If the motor is turned off, pressing the ‘+’ key will activate the motor at 1° (1st)
speed. If the motor is operating, pressing the ‘+’ key will increase motor speed up
to the maximum.

Timer Key

If the motor is active, pressing the timer key will activate/deactivate the timer
function

Code Change
(only in case of
malfunction)

Press the “Luce” (Light) key together with the “Timer” key of the remote control
until the blue LED begins to slowly flash. If the “-” key of the remote control
is pressed within 5 seconds, the new code will be generated and memorised.
Memorisation is confirmed by 3 brief flashes of the LED.
To return to the default code, apply pressure on the “-” key together with the “+”
key for over 5 seconds. Memorisation of the default code will be signalled with 3
brief flashes of the LED.
Each time that a new code is generated or that the default code is set in the
remote control, it is necessary to also carry out the previously described Remote
Binding (Light Key of the pushbutton) procedure.

FILTERS

REMOVING AND REPLACING’S INSTRUCTIONS

H

1.   METAL FILTERS

Open the panel (see fig. H3). Use handle A to remove the metal grease filter.

A

2.   CHARCOAL FILTERS

To replace the charcoal filters, proceed as follows: remove the metal filters as described
above. The two filters located at the ends of the motor can now be easily accessed.

To install the new fi lters see picture.

To order new charcoal filters contact the distributor/retailer.

VALID ONLY FOR ITALY. Download the appropriate order form from:


www.falmec.com (access the assistance drop-down menu).

3.  INSTRUCTION FOR REMOVABLE PANEL

Follow the instructions on fig.H3 to remove the panel.
