23

Button -

 By pressing the key the motor speed reduces.
 Speed 1, 2 and 3 is displayed by the n. of switched on LED, excluded light and timer LED.

Button +

 By pressing the key the motor speed increases.
 Speed 1, 2 and 3 is displayed by the n. of switched on LED, excluded light and timer LED.
 (In the 4 speed version the + key shows an intermittent light. The 4th intensive speed is timed
and after about 15 minutes the motor automatically switches to 3rd speed).

Mode button

 Function: range hood motor switch-off and switch-on.
 The

wanted speed

 enables starting the motor with last selected speed prior to previous

switch-off.

Timer button

 This function enables the automatic switch-off of the range hood after 15 minutes of function-
ing at previously set speed (button with intermittent light).

RADIO CONTROL OPERATING AT 433.92MHZ.
Technical characteristics:

Power supply

3V lithium battery (type CR2032)

Trans. consumption

6mA

Antenna incorporated
Oscillating type

SAW

Working temp.

-10°C to + 55°C

By pressing one of the keys the led will illuminate and indicate the transmission of the code. If
the led does not illuminate, the battery may require replacing.

Replacing the battery: open the rear cover and insert the battery respecting the correct
polarity.

  ATTENTION! If the battery is replaced with one that is of the wrong type there is the possibi-

lity of an explosion.

When discharging the battery, follow the respective regulations that are currently in force.
The manufacturer

Falmec S.p.A. - Via dell’Artigianato, 42 - 31029 Vittorio Veneto (TV) ITALY

declares that this radio control conforms to all of the technical regulations related to the pro-
duct and within the application confines of the directive 1999/5/CE.
All of the necessary radio frequency tests have been performed.
ETSI EN 300 220-2 V2.1.2 (2007-06)

EN 60950-1 (2001)

ETSI EN 301 489-1 V1.4.1 (2002)

EN 50371 (2004-06)

ETSI EN 301 489-3 V1.4.1 (2002)

INSTRUCTION FOR CHANGING THE FALMEC RADIO CONTROL

(to be used only

in the case of malfunction due to interferences)

Disconnect the device from the mains.
To enter in the “change code mode” the button “Luce” and “Timer” (remote control) must
be pressed together for more than 3 seconds. After 3 seconds the LED starts flashing slowly.
Now, if you press the button “-“ (remote control) within 5 seconds a new code is generated in
casual mode and memorized within the radio control. The memorizing is confirmed by 3 quick
LED flashings.
To get back to the default code: press “-“ and “+” (remote control), together for more than 5
seconds. After 5 seconds, the default code is memorized within the radio control. The memo-
rizing is confirmed by 3 quick LED flashings. Plug the device to the mains and check that lights
and motors are off. Press the timer button on the push-button panel for 2 seconds and, when
