19

English

The ouside of the range hhod should be cleaned using a damp cloth and neutral liquid
detergent or denatured alcohol.

In case of fingerprint-less finish (fasteel) clean only with water and neutral soap using
clean with a soft cloth, rinse and wipe dry thoroughly. Do not use products that contain
abrasive substances, rough cloths or cloths specifically designed for cleaning steel. Using
abrasive substances or rough cloths will inevitably damage the finish of steel. The steel
surface will be irrevocably damaged if the instructions above are not complied with.

Keep these instructions together with the instructions for use of your hood.

The manufacturer accepts no liability for any damage caused by non-compliance with the
instructions above.

4.  CLEANING THE INSIDE OF THE APPLIANCE

The electrical parts or parts of the motor assembly inside the range hood must not be
cleaned using liquids or solvents.

  Do not use abrasive products. All the above operations must be performed after having dis-

connected the appliance from the mains power supply.

WARRANTY

M

The new equipment is covered by warranty.

The warranty conditions are provided by the distributor.

  The manufacturer is not liable for any inaccuracies in this booklet resulting from printing or

transcription errors. The manufacturer reserves the right to modify its products as it consid-
ers necessary or in the interests of the user, without compromising their essential safety and
operating characteristics.

HOOD INSTALLATION

N

O1 - INSTRUCTIONS FOR WALL-MOUNTED MIRABILIA HOODS
Phase 1

- Place the support bar next to the wall (A-Fig. O1), at a height above the cooktop which cor-

responds to X+300 mm.

- With a spirit level check that the bar is horizontal. Mark a point at each end of the bar.
- Drill the holes, fit 2 ø8mm expansion joints and screw in the bar.

Phase 2

-  Fit the hood to the support bar (Fig. O2).
-  Adjust hood alignment with the relevant screws: The top screw (B) adjusts the distance from

the wall. The bottom screw (C) adjusts the vertical sliding movement.

Phase 3

-  To prevent the hood from detaching if pressure is exerted from beneath, secure it to the wall

with the brackets supplied (fig. O3).

-  Fit pipe/hose (E) into (D).

Phase 4

  Place extension (H) in the chimney (G) and fasten this assembly to the body of the hood

using screws (V1).

- Slide the extension (H) until it is positioned at the desired height.
- Once you have found the best position, lean the bracket (L) on the wall, verify the horizontal

alignment with a spirit level and mark 2 drilling points at the ends.

- Drill the holes, insert 2 expansion bolts of 4mm ø and fasten the bracket (L) with the relative

screws.

- Tighten the extension (H) to the bracket (L) using screws (M).
