26

To switch the hood off, it will be necessary to firstly select the 1st velocity and then repress
the same Key.

5: 4th Velocity

 When

the

LED is switched-off and another velocity activated

, pressing the Key (either

prolonged or not) implies the selection of the 4th velocity, switching-on of the respective
LED and switching-off of the LED associated to the velocity that was previously selected.

 When

the

LED is switched-off and no velocity activated

, pressing the Key will have no

effect.

 When

the

LED is switched-on, pressing the key 5

 will have no effect.

The forth velocity must remain on for a maximum of 14 minutes, after which, one must
return to the third.

To switch the hood off, it will be necessary to firstly select the 1st velocity and then repress
the same key.

6:  Light - Remote Binding
 Light:

Briefly pressing key T6 will turn the light on and off. The T6 key will light up if the light

is on.

Remote Binding (optional):

With motor and light turned off, applying prolonged pressure

on the T6 key will activate remote binding mode. The T6 Key will flash for a maximum of 10
seconds.  During flashing, at least one radio control key must be pressed.  The function will
deactivate upon completion of the 10 seconds, or earlier if a compatible remote control is
detected.

Key pressure management:


Prolonged pressure =

 finger pressed on key for at least 3 seconds, the function activates

during pressure.

Non-prolonged pressure =

 finger pressed on key for less than 3 seconds, the function

activates upon its release.

Radio control (optional):

 Place the device far from sources of electromagnetic waves

which could interfere with the range hood’s electronic functions

Maximum operating distance 4 metres.  This distance may vary in defect based on elec-
tromagnetic interference of other devices.

Function of the

remote control

DESCRIPTION

Light Key

Pressing the Light key will switch the light on/off

‘ - ‘ Key

Pressing the ‘-’ Key will decrease motor speed. If 1° (1st) speed is in gear, pressing
the ‘-’ key will turn off the motor

‘ + ‘ Key

If the motor is turned off, pressing the ‘+’ key will activate the motor at 1° (1st)
speed. If the motor is operating, pressing the ‘+’ key will increase motor speed up
to the maximum.

Timer Key

If the motor is active, pressing the timer key will activate/deactivate the timer
function

Code Change
(only in case of
malfunction)

Press the “Luce” (Light) key together with the “Timer” key of the remote control
until the blue LED begins to slowly flash. If the “-” key of the remote control
is pressed within 5 seconds, the new code will be generated and memorised.
Memorisation is confirmed by 3 brief flashes of the LED.
To return to the default code, apply pressure on the “-” key together with the “+”
key for over 5 seconds. Memorisation of the default code will be signalled with 3
brief flashes of the LED.
Each time that a new code is generated or that the default code is set in the
remote control, it is necessary to also carry out the previously described Remote
Binding (Light Key of the pushbutton) procedure.
