12
WARRANTY
M
The new equipment is covered by warranty.
The warranty conditions are provided by the distributor.
The manufacturer is not liable for any inaccuracies in this booklet resulting from printing or transcription errors. The manufacturer
reserves the right to modify its products as it considers necessary or in the interests of the user, without compromising their essential
safety and operating characteristics.
N
HOOD ASSEMBLY INSTRUCTIONS
WARNING:
Failure to install the screws or fixing device in accordance with these instructions
may result in electrical hazards.
Step 1 (fi g. 1)
- Place the support bar (A) on the wall at the same height as the cooker, at the same distance as the sum of the heights X+287 mm.
- Use a spirit level to check the horizontal alignment and draw 2 marks at each end of the bar, this is where the holes will be drilled.
- Drill the holes, insert 2 expansion plugs (ø 8mm) and fasten the bar with the relative screws (V1).
Step 2 (fi g. 2)
- Couple the hood onto the support bar.
- Gently open the door and remove the metal filters.
- Adjust the alignment of the hood by using the fixing screws. The upper screw (B) adjusts the distance from the wall, the lower one (C)
the vertical scrolling.
Step 3 (fi g. 3)
- To prevent the hood from coming out due to the pressure underneath it, install the safety brackets (S) as shown in the figure.
- For the exhaust version, connect the output fitting of the fan (R) to the external discharge with a suitable pipe (T). In the event of
installation with rear outlet, see figure 6 as well.
- Set up the electric connection only after disconnecting the power supply of the hood.
Step 4 (optional) (fi g. 4)
- Place extension (H) in the flue (G) and fasten this assembly to the body of the hood using the screws (V2).
- Slide the extension (H) until it is positioned at the desired height.
- Once you have found the best position, lean the bracket (L) on the wall, verify the horizontal alignment with a spirit level and mark 2
drilling points at the ends.
- Drill the holes, insert 2 expansion plugs (ø 4mm) and fasten the bracket (L) with the relative screws (V3).
- Tighten the extension (H) to the bracket (L) using the screws (V4).
Step 5
- Place the metal filters back on the hood and close the hood’s door.
- Power on the hood in accordance with current regulations (sec. D).
