17

English

Function of the

remote control

DESCRIPTION

Light Key

Pressing the Light key will switch the light on/off

‘ - ‘ Key

Pressing the ‘-’ Key will decrease motor speed. If 1° (1st) speed is in gear, pressing the ‘-’ key will turn off the motor

‘ + ‘ Key

If the motor is turned off, pressing the ‘+’ key will activate the motor at 1° (1st) speed. If the motor is operating, pressing the
‘+’ key will increase motor speed up to the maximum.

Timer Key

If the motor is active, pressing the timer key will activate/deactivate the timer function

Code Change
(only in case of
malfunction)

Press the “Luce” (Light) key together with the “Timer” key of the remote control until the blue LED begins to slowly flash. If
the “-” key of the remote control is pressed within 5 seconds, the new code will be generated and memorised. Memorisation
is confirmed by 3 brief flashes of the LED.
To return to the default code, apply pressure on the “-” key together with the “+” key for over 5 seconds. Memorisation of
the default code will be signalled with 3 brief flashes of the LED.
Each time that a new code is generated or that the default code is set in the remote control, it is necessary to also carry out
the previously described Remote Binding (Light Key of the pushbutton) procedure.

FILTERS

REMOVING AND REPLACING’S INSTRUCTIONS

H

1.   METAL FILTERS

To remove the metal grease-trapping filter, simply pull the handle A until releasing it from the front guide; then tilt it slightly down-
wards, and slide it out of the rear guide. To reposition the filter, repeat the operation in the reverse order.

Hoods with perimeter suction:

-

Open the panel (see fig. 1). Use handle A to remove the metal grease filter.

A

2.   CHARCOAL FILTERS

To replace the charcoal filters, proceed as follows: remove the metal filters as described above. The two filters located at the ends
of the motor can now be easily accessed.

To install the new fi lters see picture.

In case of hood with the motor box the fi lter is located on the botton part of the motor box.

To install the new fi lters see picture.

To order new charcoal fi lters contact the distributor/retailer.

VALID ONLY FOR ITALY:

 download the appropriate order form from: www.falmec.com (access the assistance drop-down menu).

3. REMOVABLE

PANEL

    Follow the instructions on fig. H3 to remove the panel.

LIGHTING

ASSEMBLY AND REPLACEMENT

I

1.   SPOTLIGHT

How to replace a square halogen light:
a)  Check that the equipment is disconnected from the power supply.
b)

Open the panel completely till 90° (see figure)

 pressing the PUSH button

c)  Replace the lamp with a similar one (halogen, max 20 W, 12 Volt, G4 connection).
d) Close the panel. If the panel does not close correctly repeat the operation at point b.

Square halogen light
