16

E

RANGE HOOD WITH OUTSIDE
DISCHARGE

 (exhaust)

In this version, the fumes and steam from the kitchen are conveyed outside
through an exhaust duct.
The exhaust conveyor that protrudes from the upper part of the range hood
must be connected to a duct that carries the fumes and steam outside. In this
version, the charcoal filters, if fitted, should be removed; to do this, see the in-
structions in point F. There must be adequate ventilation of the room when the
range hood is used at the same time as appliances burning gas or other fuels,
according to the standard.

Deviation for Germany:
When the range hood and appliances supplied with energy other than electric-
ity are simultaneously in operation, the negative pressure in the room must
not exceed 4 Pa (4x10 E-5 bar).

F

RECIRCULATING RANGE
HOOD

 (with filter)

In this version, the air passes through charcoal filters for purification, and is
then recirculated back into the kitchen.
Check that the charcoal filters are fitted to the motor, and if not, install them as
described in the instructions in point H.
If the hood is of filtering type, remove the non-return valve fitted at the motor’s
outlet.

 For maximum efficiency, the third speed should be used when there are strong

odours or a lot of steam, the second speed in normal conditions, and the first
speed for keeping the air clean with minimum energy consumption. The range
hood should be switched on when starting to cook, and left on until the odours
disappear.

G

OPERATION

1.  FIVE BUTTON CONTROL PANEL

 LIGHT-

button

Pressed: the light is on

Released: the light is off

MOTOR button - 1, 2, 3, OFF

1: starts the motor at minimum speed

2: starts the motor at medium speed

3: starts the motor at maximum speed

OFF: stops the motor
