17

2.  ELECTRONIC CONTROL PANEL

Light pushbutton

- ON: light on (the pushbutton is lit);

- OFF: light off;

Pushbutton -

Press to reduce motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (exclud-
ing the light and the timer LEDs).

Pushbutton +

Press to increase motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (exclud-
ing the light and the timer LEDs).

(In the 4-speed version the pushbutton + blinks. The fourth speed remains
on for a set duration of time. After 15 minutes the motor returns to the
third speed).

Mode pushbutton

Function: it turns hood motor on and off.

 The

function

“desired speed”

 enables to start the motor at the speed that

was selected before the hood was last turned off.

 Optional:

version with remote control (some versions only).

 WARNING:


Install the hood away from sources of electromagnetic waves, as these
could affect the correct operation of the electronic system.

Maximum operating distance: 5 metres. The maximum operating distance
could be less than 5 metres in case of electromagnetic interference by
other equipment.

Light pushbutton on remote control:  light on/off.

– and + pushbutton: increase/decrease speed (to start the motor press
either the + or the – pushbutton).

Timer pushbutton: see instructions below.

Timer and ‘filter clogged’ alarm pushbutton

- This function allows the automatic turning off of the hood after running
for 15 minutes at the speed previously set (the pushbutton shows a flicker-
ing light).

- After about 30 hours of running the pushbutton indicates the need for
washing the metal filters (the pushbutton shows a solid red light). To dis-
able the alarm press the pushbutton for a few seconds until the red light
turns off. Then turn the hood off and on again to check that the alarm has
disappeared.
