Faber V-AIR KL A80 - Инструкция по эксплуатации - Страница 6

B

Short

Press or move your finger from left to right to increase the speed from

1 to 2, 3, Intensive.
The intensive speed is timed for 6 minutes. At the end of this time the

system automatically returns to the previously set speed.
Repeat  the  operation  in  reverse  to  decrease  the  speed  (from  right  to

left).

The  display  shows  the

selected speed.
If  the  Intensive  speed  is

selected  the  display

shows an animation.

Long  press  on

the  leftmost  lines

when  all  loads

are  off  (motor

and lights)

Keypad Lock

 function

Activates/deactivates the keypad lock for hood cleaning.

All LEDs flashing

Long  press  on

the

rightmost

lines  when  all

loads  are  off

(motor

and

lights)

Induction/Gas Cooktop Selection

Select the type of cooktop in use, either Induction or Gas.

The Induction Cooktop is set by default.

1  Flashing  LED  A:  con-

firms

the

Induction

Cooktop selection.

2  Flashing  LED  A:  con-

firms  the  Gas  Cooktop

selection.

C

Short

Switches the lights on/off at maximum intensity.

If  there  is  an  induction  cooktop  paired  with  the  hood  and  the  hood  is

off,  as  soon  as  the  induction  cooktop  is  turned  on,  the  hood  lights

automatically turn on at the maximum intensity.

Fixed

Long  press  with

all  loads  off  (mo-

tor and lights)

K-Link pairing

Before  starting  the  procedure  follow  the  specific  instructions  of  the

manuals of the devices to be paired.

Starts the pairing procedure between the hood and compatible K-Link

devices (induction cooktop or remote control). Up to 3 induction cook-

tops  can  be  paired  and  only  one  remote  control.  See  the  manual  of

the devices for details of the operations that need to be performed on

these.

The  pairing  procedure  takes  2  minutes.  If  no  devices  are  recognised

within  this  time  check  that  you  have  previously  activated  the  proced-

ure  for  the  devices  to  be  paired.  The  maximum  number  of  linkable

devices may have been reached.

The  display  shows  an

animation:
Pairing in progress.

Upon  successful  com-

pletion  of  the  procedure

all  the  LEDs  will  light  up

for 2 seconds.

D

Short

Switches the lights on/off at medium intensity.

Fixed

Long  press  with

all  loads  off  (mo-

tor and lights)

Performs a

saturated Filters alarm reset.

The  display  shows  F  3

times, indicating that the

filter  reset  has  been

completed.

Signals  the

saturated  Metal  Grease  Filters  alarm

  and  the  need  to

wash  them.  The  alarm  is  activated  after  100  hours  of  effective  hood

operation.

With  the  motor  off,  the

display  shows  F  +  1

multiple  times  altern-

ately.

Signals  the

saturated  Activated  Carbon  Odour  Filter  alarm.

  The

alarm is activated after 200 hours of effective hood operation.

With  the  motor  off,  the

display  shows  F  +  2

multiple  times  altern-

ately.

E

Short

Delay Function

Activates/Deactivates  the  Delay  function  (automatic  shutdown  of  the

Motor and of the lighting delayed by 30').
Cannot be activated with Intensive or 24h function.
Deactivate  the  function  by  pressing  the  same  key  or  press  the  A  key

for about 1 second to shut down the motor.

LED A remains lit (fixed)

and  LED  E  lights  up.

The  display  shows  an

animation.

Long  press  with

light or motor on

24h Function

Activates/Deactivates  the  motor  in  the  24h  Air  Exchange  mode,  a

speed  that  allows  suction  of  10  minutes  every  hour,  for  a  24-hour

cycle.

Cannot be activated if the Intensive or Delay modes are active.

LED A remains lit (fixed)

and  LED  E  flashes.  The

display  shows  an  anim-

ation.

Long  press  with

all  loads  off  (mo-

tor and lights)

K-Link unpairing

Starts  the  procedure  for  the  cancellation  of  all  compatible  K-Link

devices previously paired with the K-Link pairing function.

Upon  successful  com-

pletion  of  the  procedure

all  the  LEDs  flash  5

times.

6
