F

Short

Wi-Fi connection

Activates/Deactivates the Wi-Fi Connection function.

Note:  the  Wi-Fi  function  is  automatically  activated  when  the  user  re-

quests the Wi-Fi configuration procedure.

Flashing:
connection  to  domestic

network in progress.

Fixed:
Wi-Fi  connection  activ-

ated

Long  press  with

all  loads  off  (mo-

tor and lights)

Wi-Fi configuration

Activates/Deactivates the Wi-Fi set-up procedure.

Before  starting  the  procedure  use  the

Faber  Cloud  App

  to  register

with the IOT Faber system. Then follow the instructions to add a new

device and register the domestic router.

If  the  procedure  is  not  successfully  completed  within  a  few  minutes,

deactivate  it  by  long  pressing  the  key  again,  then  make  another  at-

tempt.  The  hood  will  nonetheless  abandon  the  procedure  if  it  is  not

successfully completed within 15 minutes.

The  display  shows  an

animation:
configuration  procedure

in progress.

Upon  confirmation  that

the  procedure  was  suc-

cessful, all the LEDs will

light up for 2 seconds.

G

Short

AUTO Mode

Activates/Deactivates the Automatic operating mode.
AUTO mode is deactivated whenever any other keys are pressed.

AUTO  mode  is  activated  when  the  key  is  pressed  or  the

Paired  In-

duction  Cooktop

  is  turned  on.  The  hood  speed  is  automatically  set

using the highest power level present on the hob. When the induction

cooktop  is  turned  off  the  last  activated  speed  is  held  for  5  seconds,

then  speed  1  for  15  minutes.  Once  the  15  minutes  have  passed  the

motor turns off. The light status does not change.

Thanks  to  the  presence  of  the

Air  Quality  Sensor

  an  algorithm  is

able to modulate the speed based on the intake air quality level.

CAUTION:

  The  algorithm  function  is  optimised  for  the  most  common

types of cooking. Uncommon preparations may produce a non-optim-

ised response.

Fixed:
AUTO mode activated.

Off:
AUTO mode temporarily

deactivated.

Long  press  with

all  loads  off  (mo-

tor and lights)

Activates/Deactivates the

Activated Carbon Filters alarm

.

With  the  motor  off,  the

display  shows  F  +  2

multiple  times  altern-

ately:
alarm activated.

With  the  motor  off,  the

display  shows  F  +  0

multiple  times  altern-

ately:
alarm deactivated.

Recommended device pairing sequence:

1 - K-Link Mode (See remote control manual)
2 - K-Link Pairing (See hood manual)
3 - Remote Control-Hood Pairing (See remote control manual)
4 - K-Link Pairing (See hood manual)
5 - Cooktop-Hood Pairing (See induction cooktop manual)

7
